Tipping Bucket Type 10m3 Mobile Refuse Compactor Station With 6x4
Hook Lift Garbage Truck
Description & Applications:
SUNY mobile conjoined refuse compression station, which is
compressor and the garbage container is become conjoined machine,
in the collection, compression and transfer process of refuse are
not isolated, suitable for day 100 tons the following residential
garbage, square, street, community etc. There is no need to
construct specific foundation, saves the construction cost, and
flexible and convenient, save time and space, and nice appearance,
no two pollution.
The device has advantages of small occupation area, high
compression ratio, low noise, economy and durability, simple
facilities, low operation cost characteristics, and with high
sealing performance, waste collection, compression, transport
process to produce odor will not leak, 100 % case of sewer leakage.
Our company’s existing two type conjoined compression station can
choose for you, two types can use international general assembly
the whole truck ( also know as the hook arm truck ) for
transportation and unloading, are near the front feeding working
Tipping bucket type characteristics :
Tipping bucket and feed mouth can be a very good fastening sealing,
namely the bucket itself is feeding cover, garbage into at the same
time, the feeding mouth instantly is tipping bucket real-time
close, thus ensuring the rubbish and dust from overflowing. As a
result of the tipping bucket volume, lifting the strong box,
throughput, so it is very suitable for industrial zone, high
compression efficiency, more environmental, protection.
Specifications:
10 CBM Tipping Bucket Type Mobile Refuse Compactor Station
Model | SYGTB10IRC |
Garbage disposal per day | ≥ 40 ton |
Compression method | horizontal |
Load volume | 10 m3 |
Garbage throughput | 80 m3/h |
Compression force | 340 kN |
The compressor stroke volume | 1 m3 |
Garbage fixed bucket volume | 1.5 m3 |
Cycle time | ≤ 38 s |
The compressor size | 396x * 1460 mm |
Both sides hopper size | 1635 * 1525 mm |
The compressor stroke | 1400 mm |
Equipment dimensions | 4700 * 2192 * 2175 mm ( L * W * H ) |
Power source | Cartridge, waterproof design |
Motor | 5.5 kw, 380 V / 50 Hz |
Equipment total weight | 3.8 T |
Max. System pressure | 20 Mpa |
Control method | PLC Intelligent control system ( optional Electronic control buttons ) |
Rear door locking system | Standard Manual operation ( optional hydraulic cylinder operation ) |
Standard options | The phase converter, Vernier |
Color | optional |
