Automatical Acf Attachment Machine Hot Bar Soldering Machine
CW-ACF02
Features:
* Programmable logic controller (PLC) control system, so that the
device is stable and reliable
* Pulse heating, can be sub-set temperature, real-time display of
temperature curves
* Color touch screen, Chinese/English menu, you can store multiple
sets of operating parameters, all the
parameters simple and intuitive
* Single head, dual table, rotary pick and place feeding platform,
improve work efficiency
* Two camera system on the right place, with dual monitors, product
alignment clearly to ensure the quality
* Two-button start switch, emergency stop protection devices to
ensure safety
Parameters:
| Heating mode: Thermostatic heating | Power: 220V,800W |
| Max thermode Length : 75mm | Attachment precision: ±0.1mm |
| ACF width: 1‐6mm | Machine size: 800×600×1400mm |
| Pressure range: 6‐30kgf/cm2 | Time control: 0.1S‐999H ±0.1S |
Processed products L:10‐120mm, W:10‐
size: 120mm | Temperature control:
room temperature ‐
300±1℃ |
Gas source:
1‐5 kgf/cm2
Compressed air | Net weight: 130kgs |
Process:(FPC and the PCB welding, for example)
* Manually placed on the PCB of the fixed mold station A
* FPC manually placed on the A station displacement Mould
* Press the button on the vacuum adsorption FPC, watch display,
manual adjustments are positioned to
* Press the start button by 2 hands, the turntable rotated into the
A station just below the indenter into the
mold
* Heat head drop hot, and holding the set time
* Heat head rises, turntable rotation exit
* A station manually remove the product on the mold
* A crimping station, while the material and can be put on the bit
manipulation in B station
