Large Format Dx7 Head Eco Solvent Printing Machine 1.8m In Flex
Banner
Speed,stablity,precision,all those factors do matter for highly
competitive signage market,we get them and offer you the A-starjet
7703 series.
Detailed Product Description
| Printing Width: | 1800mm | Applications: | Flex Banner |
| Certification: | CE | Media Width: | 1800mm |
Specifications:
Item | A- Starjet 7703 |
Print head | Three DX7 print head |
Number of nozzles | 1440 nozzles per head |
Color | 4 Colors:Cyan,Magenta,Yellow,Black |
Resolution | 1440dpi(max) |
Height of print head | 2～5mm |
Size of ink droplet | 1.5～21pl |
Printing width | 1800mm |
Speed | 3pass 50sq.m per hour 4pass 38.6sq.m per hour 6pass 28.0sq.m per hour 8pass 19.0sq.m per hour |
Media width | 1900mm |
Media take up | Yes |
Media feeder | Option |
Media payload | 70kgs |
Heating system | Print heater and Post heater with PID temperature control temperature range:room temperature to 80℃ |
Ink | T5.5 eco-solvent ink ST5.5 water-based dye ink T7 reactive printing ink |
Ink cartridge | 8×350ML continuous ink supply, Optional bulk system |
Rip software | iPrint3.0 |
Control software | Print console |
Operation system | MS Windows XP ﹠ Windows 7 |
Interface | USB2.0 |
Power voltage | AC 220～240V 50～60Hz or AC 110～120V 50～60Hz |
Printing environment | Temperature:20～25℃,humidity:40-60% |
Printer dimension | W2840×D900×H1250mm |
Packing dimension | W2920×D980×H700mm |
Net weight | 220kgs |
Gross weight | 300kgs |
Description:
1. Use three Epson DX7 print head
2. Comprehensive Media Handling
3. 1.8m Printer also Available
The model use three DX7 print heads will definitely replace the previou printers which
use DX5 print
heads. And DX7 print head has longer and more durable working life.
The improvement of printing
precision makes the ink droplets smaller, and it’s stability is
better than DX5 print head’s.
Also A-Starjet printer has the standard media handling includes the feeder & take up.
Compared with other printers, it has own advantage.
1. Print Head: 3 pcs Epson DX7 print head, each print head has 1440
nozzles. Currently Epson is not
encrypted for DX7, so the buyer no need to worry about the print
head when he / she buy this kind machine.
2. Printing Width: the maximum width can be up to 1.8M / 70 Inch.
3. The only step need for adjust the print heads is to insert the
print head into the carriage. It doesn’t need
to be adjusted for several times and dairy maintenance is quite
easy and can be learned quickly.
4. Eco-solvent ink: it is eco-friendly, the smell of the ink is
light which is suitable to use the printing media in
indoor and outdoor both.
