    2.54MM Pitch Female Pin Headers Connector , 40 Pin Header DIP Dual 90 Degree For PCB

    Ask Lasest Price
    Brand Name : PHCONN
    Model Number : Pin Header
    Certification : ISO9001 : 2008 , SGS , RoHs
    Price : USD 0.1 ~ 5 PCS
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 5,000,000 PCS / Month
    Delivery Time : 7 - 10 Work Days
    • Product Details
    • Company Profile

    2.54MM Pitch Female Pin Headers Connector , 40 Pin Header DIP Dual 90 Degree For PCB


    2.54MM Pitch Female Pin Headers Connector DIP Dual 90 Degree For PCB


    Specifications


    Gender

    Feamle

    Pin

    Round, Tin / Gold plate

    Layer

    Dual/double

    Number of Row

    single,double

    Orientation

    Vertical, Right angle

    Termination

    Through hole, DIP, SMT



    Material:

    1. Housing Material: Glass Filled Polyester(UL94V-0),NYLON, LCP
    2. Contact Material: Phosphor Bronze
    3. Plating: Contact Area-Selectine Gold Plating.

    4. Cap: Glass Filled Polyester(UL94V-0),NYLON, LCP


    Electrical:

    Current Rating 1 AMP
    Voltage Rating 1.25 VAC
    Insulation Resistance 1000MΩMin
    Withstanding Resistance 500VAC
    Contact Resistance 20mΩMax



    Environmental:

    1. Storage Temperature -40°C~105°C Relative Humidity <80%.
    2. Opration Temperature -40°C~+105°C

    Lead-free process,compliant RoHS


    Why Choose PengHui

    Quality :

    Except the plating , From Design tooling , stamping , Injection molding , assemble , Testing , packing .All the step are doing by ourself . So we can control the quality .

    Manufactured under strict controls

    RoHS compliance

    ISO 9001:2008

    OEM for PULSE

    UL Certification

    Active Environmental policy

    Reach Cetitifaction

    Every module tested 3times (not just batch tested)


    Unit Price

    Charge only 35% ~ 60% of Pulse , (Midcom), Bothhand Belfuse, Tyco, Halo,....Etc

    All the step are doing by ourself. So we can control the cost
    PHC have more than 30 units automation equipments to product as possible
    PHC consists of 3 subordinations , located partly in Hunan ,Hubei ,Guangdong .
    With large scale of production lines, we can reach to cost reduction at the most extent

    Service

    PHC Offer good pre-sales & after-sales service &Strong technical support

    1. New Project: Strong technical and ideal support your new design
    2. Existing projects: Try to help customer to save the cost to offer the good quality product and save time.
    3. Free Samples:3-5 PCS of each part number.
    4. Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.
    5. Customer complaint:24-48 hours reply 8D report.
    6. Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,or repair kits if

    customers are not satisfied)


    Design &Technical strength

    We have many more than 20years experience in connector industry engineer can support your new
    project.Design a new tooling time : 30-45 workdays


    A set of mould



    Part Of Terminals





    Wish To Be Your Best Supplier and Supporter In Your connector Solutions

    ------------- PHC Sales & Support Team
