    PP Series Sulzer ESCHER WYSS Salt Centrifuge Two Stage Crystal Pusher Type Centrifuge

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PP
    Certification : ISO9001&ISO14001,CE
    Payment Terms : T/T
    Supply Ability : 20 sets/month
    Delivery Time : 90 days
    Price : USD20000-100000/SET
    • Product Details
    • Company Profile

    PP Series Sulzer ESCHER WYSS Salt Centrifuge Two Stage Crystal Pusher Type Centrifuge

    PP Series Sulzer ESCHER WYSS Salt Centrifuge Two Stage Crystal Salt Pusher Centrifuge



    Description


    This centrifuge series is called PP, it is a 2-stage pusher centrifuge, a kind of perforated basket centrifuge, both continuous and effective. It works like this: the mixture is fed and distributed continuously and evenly into the first stage basket. Most of the mother-liquor in the feed, acted by centrifugal force, departs through the sieves into the liquor-collecting casing where it will be discharged out of the machine. The first stage basket rotates and reciprocate, pushing the formed product cake into the second stage basket .The cake can have sufficient retardation in the centrifuge with being acted on by more centrifugal force, and therefore, the desired humidity of the cake can be guaranteed. Afterwards, the cake is continuously discharged out of the basket. In case of high purity for the solid product, the effective washing can be carried out in the centrifuge. If necessary, the washing agent and the mother-liquor can be discharged separately.



    Useage:
    chemicals : glaubers salt,salt, boric acid, ascorbic acid, adipic acid, sodium chloride, iron sulphate, sodium sulphate, copper sulphate, sodium bichromate.
    fertilisers : ammonium sulphate, potash, urea, calcium nitrate, potassium sulphate.
    food stuff animal feeds : extraction residues, meat pulp.
    benefication : rock phosphate, gypsum, ores, coal.
    Special designs, e.g. gas tight pusher centrifuge, explosion proof, etc.




    Specification


    Model

    PP-40

    PP-50

    PP-60

    Basket diameter (mm)

    290/360

    438/500

    560/630

    Stroke of pusher mechanism

    (times/min)

    40-80

    40-80

    70-80

    Machine speed (rpm)

    2500

    2000

    1360

    Operative oil pressure (Mpa)

    2.5

    2

    8

    Motor of oil pump (kw)

    5.5-7.5

    22

    13-30

    Main motor (kw)

    11-15

    37-45

    55

    Output (t/h)

    5-7

    12

    20

    Sieve slot

    To be decided

    Operation temp. (°C)

    Below 105

    Below 105

    Below 105

    Overall dimension (mm)

    2346*1090*1006

    3660*1420*2078

    3127*1700*1955

    Weight (kg)

    2600

    4400

    4860
