RDER series centrifugal exhaust fan:
Material: stainless steel for option
model:RDER-1000/1250/1400
Type: Axial Flow Fan
mounting: shop window / wall fan
Voltage: 380V
Power: 1.1KW
Frequency: 50HZ
Products Features:
1) Fan Frame: made from highly galvanized steel sheets in order to
assure highest strength and strong resistance to corrosion
2) Blade: 6 pieces stainless steel blades and the fan has all
passed the experiment of homeostasis with big air volume, without
deformation n, no breaking, attractive and durable.
3) Belt Pulley: The V type belt pulley is aluminium magnesium alloy
injection moulded, light weight, high-strength.
4) Bearing: France imported bearing, high intensity, low noise,
long service life..
data
|
|
|
|
|
|
|
|
|
|
Model specification | Diameter biades (mm) | Blades rotational speed rpm | Motor Rotational speed rpm | Air flow (m³ /h) | Total pressure (Pa) | Noise decibels | Import power (W) | Rated voltage (v) | Outer Size(mm) (h*w*t) |
DHSV-700 | 700 | 650 | 1400 | 25000 | 65 | ≤65 | 370 | 380 | 800*800*400 |
DHSV-750 | 750 | 630 | 1400 | 28000 | 65 | ≤65 | 370 | 380 | 900*900*400 |
DHSV-900 | 900 | 610 | 1400 | 30000 | 70 | ≤70 | 550 | 380 | 1000*1000*400 |
DHSV-1000 | 1000 | 600 | 1400 | 32500 | 70 | ≤70 | 750 | 380 | 1100*1100*400 |
DHSV-1100 | 1100 | 460 | 1400 | 38000 | 73 | ≤70 | 750 | 380 | 1220*1220*400 |
DHSV-1250 | 1250 | 439 | 1400 | 44000 | 56 | ≤70 | 1100 | 380 | 1380*1380*400 |
|
