    DM422 Digital Low Voltage Stepper Motor Driver With Low Noise , Black Color

    Ask Lasest Price
    Brand Name : JCZ
    Model Number : DM422C
    Certification : CE
    Payment Terms : T/T
    Supply Ability : 1000Set
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    DM422 Digital Low Voltage Stepper Motor Driver With Low Noise , Black Color

    Product introduction:

    DM422 digital low-voltage stepper motor driver, using the latest 32 bit DSP technology, suitable for driving 39, 42 series of motors, with excellent performance in the middle and low speed.

    Can be set within the arbitrary subdivision of 256 and the current value of any current within the rated current, to meet the needs of the application of most small devices. With the built-in micro technology, even in the low subdivision conditions, it can achieve high segmentation results, the low speed operation is very smooth, noise is very small.

    Internal integration of the parameters of the auto tuning function, can automatically generate the optimal operation parameters for different motors, to maximize the performance of the motor.


    Product parameters:


    ExplainDM422
    minimum valueTypical valueMaximum valueCompany
    Output current (peak value)0.5-2.2A
    Input supply voltage182436VDC
    Control signal input current71016mA
    Step pulse frequency0-75KHz
    Insulation resistance500
    Cooling modeNatural cooling or forced air cooling
    Use environmentoccasionCan not be placed next to other heating equipment, to avoid dust, oil, corrosive gas, humidity is too large and strong vibration place, there is no combustible gas and conductive dust;
    temperature0——+50℃
    humidity40—90%RH
    Vibration10~55Hz/0.15mm
    Save temperature-20℃~65℃
    weight150 gram
