Product Name:
Street lighting poles with LED lights.
Design:
All lighting poles could be tapered octagonal, hexagonal, conical
or square. The poles can also be customized based on end-users'
requirements on its style. We can design the poles based on
customer's supplied technical conditions: Wind speed, pole height,
arm length, lighting fixture's property and dimensions, as well as
road distribution and conditions if available.
Cross-section Shape:
Round, octagonal, hexagonal, square or customized.
Material:
Q235, SS400, Q345, from big material companies in China such as
Baosteel, Ansteel. Q345, minimum yield strength>=345n/mm2;
Q235/A36,minimum yield strength>=235n/mm2; Materials comply with
Australian Standard AS1594, Hot rolled steel flat products;
Australian Standard AS3678, Hot rolled steel plates; Australian
Standard AS3679, Hot rolled steel bars and sections.
Material Tolerance:
Maximum -0.02mm
Surface Treatment:
Hot dip galvanization; polyster powder coated after hot dip
galvanization; or customized.
Hot-dip galvanization standard : Australian/New Zealand Standard
AS/NZS 4680:1994. Or BS 729 / ISO 1461 ASTM A 123. Or China
standard GB/T:13912-2002
Pole Height:
2m-14m
Welding:
Welding complies with AWS D1.1/D1.1M-2004. Or Australian/New
Zealand Standard AS/NZS 1554.1.2004. Welding of steel structures.
Or BS 5135
Production Process:
Material cutting - bending - submerged arc welding for longitudinal
weld, baseplate fillet welding, components butt welding - deburs
and polishing - hot dip galvanization – pole straightness
correction - polyster powder coating - packaging
Quality Control:
Controlled by inspectors for every process.
Certificate:
CE (Acc. To EN40-5: 2002.)
Our lighting poles that sent to Europe are with CE mark.
Packaging:
Wrap two ends with fabrics for galvanized pole; bubble wrapper and
thick cloth wrapped for powder coated poles. Or further packaged in
bundles with steel straps and fumigated timbers.
Application:
Streets, roadways, highways, squares, parks, etc.
