    Auto CNC Metal Spinning Lathe For Spin Lamps / Art Wares / Kitchenware / Auto Fittings

    Ask Lasest Price
    Brand Name : jinqiu
    Model Number : SG1700
    Certification : CE and CQC
    Price : USD or RMB
    Delivery Time : 60 DAYS
    • Product Details
    • Company Profile

    Auto CNC Metal Spinning Lathe For Spin Lamps / Art Wares / Kitchenware / Auto Fittings

    Spin lamps, art wares, kitchen ware and auto fittings—CNC turning and spinning machine


    The machine can be used in following details:

    SG1700 It has many patents issued by the State Intellectual Property Office. This machine is practical, professional and strong. It has high production efficiency and can complete horn, bucket, cone type, parabolic products .CNC Spinning and Turning Machine(Single Roller) is especially developed to spin lamps, art wares,kitchenwares and auto fittings.. It can also process threading, trimming, flanging and rolling at the same machine tool. The machine can spin many materials such as carbon steel, stainless steel, aluminum and copper etc. It has solved the traditional problems such as lack of skilled workers. With advanced digital control, it is easy to operate. The machine can improve the production efficiency, machining accuracy and saving the cost of human resources. It is the ideal processing machine for light, automobile, mechanic and other manufacturing industries.


    Standard Configurations & Main Features:

    * Configuration cooling pump.

    * Mobile manual pulse generator makes easy to operate.

    * Semi-enclosed shield.

    * Siemens 808D as standard CNC system which has USB port.

    * Meehanite cast iron after aging treatment, with high quality and less deformation.

    * Adopt independent spindle unit to ensure good movement precision, stiffness and stability.

    * Precision ball screws ensure dynamic performance well and positioning accurately.

    * Feeding axles are driven by servo motors.

    * Spindle motor is Servo controlled.

    * Hydraulic tailstock.

    * Integrated automatic lubrication system makes the maintenance more reliable.


    Technical characters:
    ItemsTechnical Parameters
    ModelSG1700
    Amount of Rollers1+
    Max. Diameter of BlankΦ1700 mm
    Max. Turning Diameter<Φ1700 mm
    Max. Length of Work Piece1000 mm
    Thickness of Blank0.5-12 mm (Aluminum,Copper) 0.5-10 mm ( Carbon Steel) 0.5-6 mm ( Stainless Steel)
    X-axis Stroke800 mm
    Z-axis Stroke1000 mm
    X-axis Force100 kN
    Z-axis Force100 kN
    Tailstock Force80 kN
    Guide Rail TypeLinear Guide Rail
    Width of Bed600 mm
    Rapid Traverse X/Z-axis8/12 m/min
    Servo Torque X/Z-axis70/70 N.m
    Pulse Equivalent X/Z-axis0.001 mm
    Positioning Accuracy0.020 mm
    Repetitive Positioning Accuracy0.01 mm
    Spindle NoseC11
    Spindle Taper120(1:10)Metric
    Spindle BoreΦ110 mm
    Spindle Speed1000 rpm
    Taper of Tailstock QuillMT5
    Tailstock Stroke900 mm
    Stroke of Tailstock Quill500 mm
    Diameter of Tailstock QuillΦ140 mm
    Amount of Tools / Shank Size6/30x30 mm²
    Spindle Motor Power57 kw
    Hydraulic Power5.5 kw
    Machining AccuracyIt 6
    Surface RoughnessRa 1.25
    Service Voltage380V AC
    Power Capacity75 KVA
    Overall Dimensions4.0x2.5x2.0 m³
    Net Weight11000 kg
