Transparent 4 Wire POS Touch Screen For Touch Monitor , Glass Touch
Panel
Quick Detail:
1.Material: Glass + film
2.Aspect ratio: 4:3
3.Input method: Finger or touch pen
4.Thickness: ITO Glass: 1.1~1.8mm, ITO Film:0.188mm
5.Surface hardness: 3H
6.Detection method: Resistive
7.Pen hitting life:≥10,000,000/point
8.Pen sliding Durability:≥500,000 times
9.Finger Touch life:≥35,000,000 times
10.Surface resistance:30Ω~350Ω
11.Isolation resistance:≥20MΩ @ DC 25V
Specifications:
| Size | 14 inch |
| Structure | Film + Glass |
| Connector | Pin 4 plug connector |
| Thickness | 1.4 ± 0.15 mm |
| Touch Media | Finger, Touch Pen, Glove |
| Type | 4 Wire Restistive Touch screen |
| Ratio | 4:3 |
| Resolution | 4096*4096 |
| Response Time | ≤ 10 ms |
| Supply Voltage | 5V DC; 35 mA |
| Transparent | ≤ 78% |
| Screen Resistance | X:100-500Ω Y:200-1000Ω |
| Insulation Resistance | ≥20MΩ(10V DC) |
| Pressure | 30-150g |
| Surface Hardness | 3H |
| Life Span | > 1,000,000 time knocking ;
≥ 100,000 time in paddling |
| Operating Temperature | - 10ºC ~ +60ºC |
| Storage Temperature | - 20ºC ~ +70ºC |
| Storage Humidity | 20 ~ 85% RH (except congeal fog) |
| Custom Service | Available |
