    NEW TENMA 7" TM070RDH10 Custom Lcd Display High Brightness 60 Days Warranty

    Model Number:TM070RDH10


    NEW TENMA 7 "TM070RDH10 LCD Display 60 days warranty

    1,TIANMA TM070RDH10 Mechanical Features

    Panel Size :7.0 inch
    Dot Resolution :800(RGB)×480 (WVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :134 PPI
    Aspect Ratio :16:9 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0642×0.1790 mm (H×V)
    Pixel Pitch :0.1926×0.1790 mm (H×V)
    Weight :TBD
    Surface :Antiglare
    Active Area :154.08×85.92 mm (H×V)
    Bezel Area :157.08×89.39 mm (H×V)
    Outline Dimension :164.9×100 mm (H×V)
    Outline Depth :5.7±0.3 mm
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    2,TIANMA TM070RDH10 Optical Features

    Display Mode :TN, Normally White, Transmissive
    Brightness :350 cd/m² (Typ.)
    Contrast Ratio :500 : 1 (Typ.) (Transmissive)
    Display Color :262K/16.7M (6-bit / 6-bit + Dithering)
    Color Gamut :50% NTSC (CIE1931)
    Response Time :25 (Typ.)(Tr+Td)
    Viewing Angle :70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :12 o'clock
    White color Chromaticity :Wx:0.315; Wy:0.330
    White Variation :1.33 (Typ.)(9 points)

    3,TIANMA TM070RDH10 Electronics Feature

    Vertical Frequency :60Hz
    Reverse Scan :Yes (U/D, L/R)
    Time Controller (T-CON) :Embedded T-CON

    4,TIANMA TM070RDH10 Backlight System

    Lamp Position :Edge light type
    Lamp Type :WLED
    Lamp Amount :3S8P
    Lamp Shape :Array
    Lamp Life Time :20K(Typ.) (Hours)
    Lamp Voltage :9.6/10.8V (Typ./Max.)
    Lamp Current :160/200mA (Typ./Max.)
    Lamps Power Consumption :1.54/2.16W (Typ./Max.)
    Interface Type :Included in panel signal interface
    Lamp Driver Board :No

    5,TIANMA TM070RDH10 Signal Interface

    Signal Category :TTL
    Signal Class :Parallel RGB (1 ch, 8-bit)
    Input Voltage for Panel :3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
    Input Current for Panel :10/55/0.3/0.3mA (Max.)(ICC/IDD/IGH/IGL)
    Voltage for Display Signals :0≤VIL≤0.3VCC; 0.7VCC≤VIH≤VCC
    Interface Type :FPC
    Signal Interface :BrandModelPin PitchPinsAmountConfiguration
    0.5 mm50 pins1 pcsDRGB-50P1C8B-115A

    6,TIANMA TM070RDH10 Packing Form

    Amount per Box :50 pcs
    Box Size :530×350×250 mm (L×W×H)
    Box Gross Weight :TBD

    Details Picture for NEW TENMA 7 "TM070RDH10 LCD Display 60 days warranty
