    High Performance 8 bit Microcontroller with 12K Bytes Flash AT89S53-24PC

    Ask Lasest Price
    Brand Name : ATMEL
    Model Number : AT89S53-24PC
    Certification : Original Factory Pack
    Price : Negotiation
    Payment Terms : T/T, Western Union,PayPal
    Supply Ability : 290PCS
    Delivery Time : 1 Day
    • Product Details
    • Company Profile

    High Performance 8 bit Microcontroller with 12K Bytes Flash AT89S53-24PC

    8-bit Microcontroller with 12K Bytes Flash


    Features

    • Compatible with MCS-51™ Products

    • 12K Bytes of In-System Reprogrammable Downloadable Flash Memory

    – SPI Serial Interface for Program Downloading

    – Endurance: 1,000 Write/Erase Cycles

    • 4V to 6V Operating Range

    • Fully Static Operation: 0 Hz to 24 MHz

    • Three-level Program Memory Lock

    • 256 x 8-bit Internal RAM

    • 32 Programmable I/O Lines

    • Three 16-bit Timer/Counters

    • Nine Interrupt Sources Programmable UART Serial Channel

    • SPI Serial Interface

    • Low-power Idle and Power-down Modes

    • Interrupt Recovery From Power-down

    • Programmable Watchdog Timer

    • Dual Data Pointer

    • Power-off Flag


    Description

    The AT89S53 is a low-power, high-performance CMOS 8-bit microcomputer with 12K bytes of downloadable Flash programmable and erasable read only memory. The device is manufactured using Atmel’s high-density nonvolatile memory technology and is compatible with the industry-standard 80C51 instruction set and pinout. The onchip downloadable Flash allows the program memory to be reprogrammed in-system through an SPI serial interface or by a conventional nonvolatile memory programmer. By combining a versatile 8-bit CPU with downloadable Flash on a monolithic chip, the Atmel AT89S53 is a powerful microcomputer which provides a highly-flexible and cost-effective solution to many embedded control applications.


    WDT Prescaler BitsPeriod (nominal)
    PS2PS1PS0
    00016 ms
    00132 ms
    01064 ms
    011128 ms

    Timer 2 Auto Reload Mode (DCEN = 1)
