Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven

    Buy cheap Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven from wholesalers

    Buy cheap Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven from wholesalers
    • Buy cheap Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven from wholesalers

    Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven

    Ask Lasest Price
    Brand Name : E&V
    Model Number : SYJ2017-I3
    Supply Ability : 1SET PER MONTH
    Delivery Time : 60 DAYS
    • Product Details
    • Company Profile

    Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven

    Ф17mm - Ф30mm Brass Rod Continuous Caster Manual Adjusting Take - Up Plate Driven


    Main Para-meter


    1 Model: SYJ2017-I3
    2 Yearly capacity: 10000mt
    3 Furnace structure: 500type three- body furnace (2melting furnace, 1 holding furnace)
    4 Casting strands: 20
    5 Casting diameter: Ф17mm → Ф30mm
    6 Casting speed: 0 ~ 1000mm / min
    7 annual working time: 7920h
    8 Liquid tracking precision: ± 2mm
    9 Take-up coil standard: φ700mm × φ1500mm × 800mm
    10 Copper melting velocity: 1270kg / h
    11 Copper melting power consumption: <350kwh / ton
    12 Take-up form: automatic adjust
    13 Take-up plate driven approach: pushed by rod, manual adjusting
    14 Material feeding method: whole piece of electrolytic copper cathode fed by electric hoist
    15 Upward driven approach: driven by the AC servo motor, transmission chain is driven by the gapless synchronous cog blet
    16 Rod clamping method: manual clamping
    17 Operation interface: date display, servo motor controlled by touch screen
    18 Total power: 500KW AC three-phase 380V


    some questions for this machine, maybe u are interested in


    1. How many hours did upcasting machine work yearly?
    Generally speaking, the working time is 7920 hours. But we advise the machine should work all year, because it can reduce the wastage.

    2. How can we add the material to the furnace?
    The whole piece of electrolytic copper cathode board fed by electric hoist. It will be more easier and safe.

    3. What's the type of take-up machine?
    Fine rod automatic winding, thick rod passive winding and whole automatic winding.

    4. Which is the controlling method?


    Frequency variation speed control,automatic taking-up and coiling, Intermittent automatic winding,copper rod coiled by pushing and Frequency variation speed control,automatic taking-up and coiling.
