Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07

    Buy cheap Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07 from wholesalers

    Buy cheap Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07 from wholesalers
    • Buy cheap Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07 from wholesalers
    • Buy cheap Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07 from wholesalers

    Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07

    Ask Lasest Price
    Brand Name : LG Display
    Model Number : LB070WV1-TD07
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 100 PCS Per Day
    Delivery Time : 2-3 Working Days after order confirmation
    • Product Details
    • Company Profile

    Wide Temperature 7.0 Inch LG LCD Panel Long Backlight Life LB070WV1-TD07

    LG LCD Panel , 7.0inch LB070WV1-TD07 400:1 Antiglare custom lcd panels


    Specifications:


    Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.


    Panel No. :LB070WV1-TD07
    Dot Resolution :800(RGB)×480 (WVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :133 PPI
    Aspect Ratio :15:9 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.0635×0.1905 mm (H×V)
    Pixel Pitch :0.1905×0.1905 mm (H×V)
    Weight :115g (Typ.)
    Surface :Antiglare
    Active Area :152.4×91.44 mm (H×V)
    Bezel Area :155.6×94.6 mm (H×V)
    Outline Dimension :165×104.6 mm (H×V)
    Outline Depth :5.0±0.3 mm
    Holes & Brackets :Without
    Landscape or Portrait :Landscape type
    Touch Panel :Without
    Display Mode :TN, Normally White, Transmissive
    Brightness :250 cd/m² (Typ.)
    Contrast Ratio :400 : 1 (Typ.) (Transmissive)
    Display Color :262K (6-bit)
    Color Gamut :45% NTSC (CIE1931)
    Response Time :10/15 (Typ.)(Tr/Td)
    Viewing Angle :70/70/45/55 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.330; Wy:0.350
    White Variation :1.40/1.60 (Typ./Max.)(9 points)

    Competitive Advantage:


    1. We are a leading manufacturer of LCD products for more than 10 years.

    2. We got the ISO9001 quality management system certification.

    3. We have our own R&D team, and accept OEM order as per customer’s design.

    4. We are the 5-years four star member of Globalsources and the Three year Gold supplier in Alibaba.

    5. Our main material LCD panels all are directly imported from Samsung and LG in Korea.

    6. All products win the certificate of CE,CCC,FCC and RoHS.

    7. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 5 days.

    8. 3-years warranty is offered.


    N&S supplies integrated LCD touch display solutions, which will make the process of your development easy. The module seals LCD, touch screen, the foundation hardware and software (driver), and universal connection (USB or RS232) to PC and embedded system.We focuses on LCD display module integrate touch screen in medium and small size between 5~12.1 inches. Touch screen technology is the most popular form in applications ranging from industry to consumer . It is more convenient compaired with key button control technology. The input signal includes HDMI, AV, VGA, S-video, DVI, YPbPr and 3G-SDI, etc.

    Details Pictures for the LB070WV1-TD07 Screen Display Panel:
