    Westfalia Structure High Speed Automatic Continuous CIP Disc Stack Centrifuges Filtration Systems For Coconut Oil

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PDSC-204SD
    Certification : ISO
    Price : USD32000
    Delivery Time : 20-60working days
    Payment Terms : D/A, D/P, L/C, Western Union, MoneyGram, T/T
    • Product Details
    • Company Profile

    Westfalia Structure High Speed Automatic Continuous CIP Disc Stack Centrifuges Filtration Systems For Coconut Oil

    Westfalia Structure High Speed Automatic Continuous CIP Disc Stack Centrifuges Filtration Systems For Coconut Oil


    Product overview:


    The drum body, drum cover, and valve of the separator are made of high-strength stainless steel, while other parts are constructed from high-quality stainless steel. The disc stack and separator shell utilize SS304 stainless steel.


    The drive structure support incorporates SKF bearings and is designed optimally to reduce the center of gravity of the drum. This design effectively minimizes vibration levels throughout the separator, enhances equipment reliability, and increases overall stability.


    During disassembly and maintenance, the drum parts can be hoisted as a single unit, making it more convenient to remove the main lock ring. This streamlined process saves time and labor, facilitating easy drum installation.


    The separator undergoes precise dynamic balancing of the drum, resulting in reduced vibration and improved stability.


    The separator employs separation factor technology, enabling the separation of challenging products. Despite its compact size, the machine offers significant capacity and high separation efficiency.


    The separator incorporates an advanced belt drive system, which enhances reliability and maintainability while reducing the cost of spare parts.


    Technical specification:


    Capacity

    < 1000L/h

    Working diameter of bowl

    Φ230mm

    RPM

    11200rpm

    Discharge type

    Self-cleaning (PLC control)

    Vibration

    ≤2.8mm/s

    Noise

    ≤85dB(A)

    Starting Mode

    Frequency Startup

    Driving Mode

    Belt Drive

    N.W.

    371kg

    Dimension (L*W*H)

    930×750×1050mm

    Motor

    Power

    7.5kW


    The details, pls kindly check PSWDB204SD-01.pdf for reference, thank you.


    Pictures:
