K Series Pneumatic Turbine Vibrators Findeva Ball Vibrators K-10
1/4 Inch
Quick Detail:
* K series Pneumatic turbine vibrator
* body material Extruded Aluminium Alloy
* body material stainless steel available
* High temperature-resistance up to 100℃
* Immediately start,stop,fast response
* lubrication free
* Port size 1/4“ G,NPT
* Working frequence and centrifugal force can be adjustable by air
pressure
* Working frequence up to 17000cycles/Minute at 6 Bar
* Strong Centrifugal force up to 5070N at 6Bar
* Low noise 60~75Dba
Properties
• Powerful
• Rated frequency 7,300- 35,000rmp
• Centrifugal force 130-4'050 N
• Continuously variable
• Can be used up to 100 °C
• HT version up to 150 °C
Field of application
• Emptying of bunkers
• Screen filters
• Vibrating tables
• Preventing adhesions in pipelines and silos
• Transporting of fine powders
• Moving of bulk materials
Construction
• Vibration by means of a ball that is guided by hardened steel
guides.
• Nylon plates on both sides to support the ball and as protection
from dust and water
• Housing with 4 mounting bores, depending on the application
Applications:
K-10 Pneumatic turbine vibrator used widely in feed material
conveyor,vibration screening,vibrating hopper,packaging
filling,foundry sand mold vibration etc
Specifications:
| Model | Vibrations
1000 rpm
2bar 6bar | Centrifugal force
N
2bar 6bar | Air consumption
I/min
2bar 6bar |
| K-8 | 25.5 | 35 | 130 | 360 | 83 | 195 |
| K-10 | 22.5 | 34 | 250 | 710 | 92 | 200 |
| K-13 | 15 | 22.5 | 320 | 870 | 94 | 225 |
| K-16 | 13 | 19.5 | 450 | 1100 | 122 | 280 |
| K-20 | 10.5 | 16.5 | 720 | 1720 | 130 | 340 |
| K-25 | 9.2 | 14 | 930 | 2050 | 160 | 425 |
| K-30 | 7.8 | 12.5 | 1510 | 3210 | 215 | 570 |
| K-36 | 7.3 | 10 | 2060 | 4050 | 260 | 675 |
Dimension:
| C | A | Width | C | D | E | F | G | H | Weight |
| | | | | | | | | BSP | G |
| K-8 | 50 | 20 | 86 | 68 | 12 | 7 | 40 | 1/4" | 130 |
| K-10 | 50 | 20 | 86 | 68 | 12 | 7 | 40 | 1/4" | 130 |
| K-13 | 65 | 24 | 113 | 90 | 16 | 9 | 50 | 1/4" | 260 |
| K-16 | 65 | 27 | 113 | 90 | 16 | 9 | 50 | 1/4" | 300 |
| K-20 | 80 | 33 | 128 | 104 | 16 | 9 | 60 | 1/4" | 530 |
| K-25 | 80 | 38 | 128 | 104 | 16 | 9 | 60 | 1/4" | 630 |
| K-30 | 100 | 44 | 160 | 130 | 20 | 11 | 80 | 3/8" | 1130 |
| K-36 | 100 | 50 | 160 | 130 | 20 | 11 | 80 | 3/8" | 1340 |
Competitive Advantage:
| Our product features: | Our Services Guarantee: |
| 1) Competitive price | 1) Prompt respond (Reply with 24 hours) |
| 2) Good quality | 2) Free Samples (Customer pay for the delivery cost) |
| 3) Professional Packaging, | 3) Registration support. |
| 4) Produce according to Customers’ instruction | 4) Photos/videos are available during production. |
| 5) None delay shipment | 5) Loading inspection, and send loading photos before shipment. |
Quality Standards :
The company for the products are brand new original products, no
second-hand and refurbished products, or leave a compensable ten
and return the full amount , but the buyer due to our purchase of
model error is not responsible for returns, another of the
company's sales of products enjoy one year from the date of
shipment quality assurance , according to the original quality
standards , during warranty with product problems , need
confirmation testing by the manufacturer , the supplier to be
solved , the demand side due to storage , use, poor maintenance
caused by lower-quality product , and not raise objections
Warranty:
All item Comes with Basic 3 Month Sellers Warranty, if item
defective in 3 Month, We will offer replacement without extra
Charger(including shipping fee)After we Receive the Defective item.
If item Defective after 3 Month, Buyers can still send it back, We
will contact suppliers or Manufactory for Warranty. Buyers Might
Need to pay the Shipping fee For resend the replaced item.
