1.Suitable for non woven fabric material.
2.can make flat bag ,box bag,t-shirt bag vest bags
3. non woven bag making machine
ONL-C Full Automatic Non Woven Fabric Box Bag Making Machine
Use: Suitable for non woven fabric, laminationmaterial. It can make
vest bags, flat bags, rope bag,square bottom bags and so on.
Feature:
1,Microcomputer control,
2,Stepping motor feeding material,
3,Photo-eye tracking,
4,automatic side-correction,
5,auto counting,
6,Gusset
7,Folding device
8,handle punch
9,computer fixed-length,
10,magnetic powder braking,
11,auto-stopping,
12,ultrasonic rolloff,
13,ultrasonic sealing bottom
14,with T-shirt bag punch and so on.
It enable the sample in good and hard sealing, high speed, high
efficiency. It is your ideal excellent environmental-protection bag
making equipment.
Main Machine Material:
Channel steel,armor plate.
Main Technical Parameters:
| Model | ONL-C700 |
| Bag Type | T-shirt bag | Flat bag | Box bag |
| Max Sealing & Cutting Length | 300-600mm | 100-700mm | 300-600mm |
| Max Sealing & Cutting Width | 150-420mm | 300-650mm | 350-550mm |
| Bag Making Speed | 20-70pcs/min | 20-110pcs/min | 20-50pcs/min |
| Material Thickness(best range) | 35-60gsm | 35-100gsm | 45-85gsm |
| Inserting Size | 30-120mm | 30-90mm | 30-80mm |
