    Seamless Stainless Steel Tubing Bender R=5D Material ASTM A312 TP316L

    Ask Lasest Price
    Brand Name : TOBO
    Model Number : ASTM A312 TP316L
    Certification : SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
    Price : US $ 10 - 100 / Kilogram
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50 Metric Ton/Metric Tons per Month
    Delivery Time : 7-30days
    • Product Details
    • Company Profile

    Seamless Stainless Steel Tubing Bender R=5D Material ASTM A312 TP316L

    Seamless Stainless Steel Tubing Bender R=5D Material ASTM A312 TP316L

    Quick Details

    Material:c.s./s.s/a.sTechnics:Butt-WeldType:Bend
    Place of Origin:Shanghai, China (Mainland)Model Number:bendBrand Name:TOBO
    Connection:WeldingShape:EqualHead Code:Round

    Packaging & Delivery

    Packaging Details:in wooden box,in pallet,in bulk
    Delivery Detail:15-30days

    Specifications

    Short Radius Bend,45/90 /180Degree,R=5D,Material ASTM A312 TP316L
    R=3D 5D 7D 10D
    we can supply all kinds of bends.welcome!


    Description of Bend:

    Production NameSeamless Steel Pipe Elbow Bend , Short Radius Bend,45/90 /180Degree,R=5D,Material ASTM A312 TP316L
    Size13.7-1219.2mm (1/4''-48''),DN8-DN1200
    WTSCH5S-XXS
    StandardANSI B16.9, ANSI B16.28, DIN 2605, ISO3419,DIN EN10253,JIS B2312, JIS B2313, MSS SP-25, MSS SP-75, BS1387
    Carbon Steel10# 20# Q235B ASTM A234 A105 A403
    Stainless Steel1Cr18Ni9Ti 0Cr18Ni9 00Cr19Ni10 0Cr17Ni12Mo2Ti 00Cr17Ni14Mo2 304 304L 316 316L
    Alloy Steel

    16Mn Cr5Mo 12Cr1MoV 10CrMo910 15CrMo 12Cr2Mo1 A335P22 St45.8

    ASTM A860 WPHY X42 X52 X60 X70

    Aluminum Steel1060,2024,2017,3003,5052,5083,6061,6083,6060,7075,8011
    Packing:Wooden case, Wooden pallet, or according to customer's requirement
    Main pipefittingsElbow ,Tee/Cross ,Reducer ,Cap ,Flange ,Bend,Stubtube,Weldolet/Threadolet/Olet,Nipple,Union,Pipe Clamp
    InspectionFactory in-house or Third Party inpection
    ApplicationPetroleum industry, Refinery Company, fertilizer industry, power station, shipbuilding,onshore platform

    In the piping system,the direction of the line pipe bend is to be changed.Elbow materials:stainless steel, alloy steel, cast iron can be calcined cast iron, carbon steel, nonferrous metal and plastic, etc.

    1,Stainless steel, ASTM/ASME A403 WP 304-304 - l - 304 - h - 304 ln - 304 n ASTM/ASME A403 WP 316-316 l - 316 - h - 316 ln - 316 - n - 316 ti ASTM/ASME A403 WP 321-321 - h ASTM/ASME A403 WP 347-347 - h

    2,Carbon steel, ASTM/ASME A234 WPB, WPC

    3,Alloy: ASTM/ASME A234 WP 11-12-1 - WP WP WP 22 - WP 91-5 - WP WP911

    4,Low temperature steel, ASTM/ASME A402 WPL3 - WPL 6

    5,High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-65

    6,Cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon luo drain, PVC, PPR, RFPP (reinforced polypropylene), etc.


    Adapted material:steel pipe, stainless steel, copper pipe, aluminum pipe;


    Recommended application industry:
    automobile fittings ( oil pipe for brake, muffler, seats), motorcycle, healthy equipment, air-conditioning,bicycle, steel furniture, sanitary wares and so on.


    Main specification

    1. Automatic recognition of power in machine and work piece, the processing is both quick and good
    2. Slow returning core, boosted by barrow, imporving the apprearance of the angle.
    3. The whole operation is in the computer, simple, quick and correct
    4. Picturized programming system: draw and modify on the stereo pipe image on the screen, makes the operation simple, quick and correct
    5. Rebound test: comparison test on the features of lots of pipe materials
    6. Single-step debugging function- a careful observe on the deformation of the pipe material during the trail manufacture of dies.
    7. Automatic drawing of the graphics of dies-clear help to develop new products
    8. Over-all inspection: hydraulic/electrical circuit/ driving systems, adsence of phase in motors/inversion, voltage, temperature, oil pressure, and automatically diagnose the troubles
    9. Passwords, keys, working hours/ recordings of quantities, are applied to management of production


    Technical parameter

    Specification/ModelDW89CNC
    Max bending diameter of tube88.9mm
    Max bending wall thickness of tube2.0mm
    Max bending radius3000mm
    Min bending radiusdepend on the tube diameter
    Max bending angle190°
    Max feeding length3000mm
    feeding methoddirect feeding / clamping feeding
    Bending speedMax 25°/s
    Rotary speedMax 180°/s
    Feeding speedMax 600mm/s
    Bending accuracy±0.1°
    Rotary accuracy±0.1°
    Feeding accuracy±0.1mm
