sartorius compression pillow block 10 ton 20 ton 30 ton load cell weighing scale

Name: sartorius compression pillow block 10 ton 20 ton 30 ton load cell weighing scale
Brand: Shelok
Price: 6 USD

Ask Lasest Price
Brand Name :	Shelok
Model Number :	SLK- CHBU
Price :	USD+6~60+Piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100+pieces+per month
Delivery Time :	5-8 work days

Add to Cart

Description of sartorius compression 10 ton 20 ton 30 ton load cell weighing scale

The load cell is made of hub-and-spoke elastomer structure and shearing stress principle.Suitable for testing various load forces.

Specification of sartorius compression 10 ton 20 ton 30 ton load cell weighing scale

Sensitivity	2.0±0.05mV/V	Operating temperature	-20~80℃
Nonlinearity	±0.03%F.S	Input resistance	750±20Ω
Hysteresis	±0.03%F.S	Output resistance	700±5Ω
Repeatability	±0.03%F.S	Safe overload	150%F.S
Creep	±0.03%F.S/30min	Zero output	±1%F.S
Insulation Resistance	≥5000MΩ	Reference excitation voltage	10-15V
Zero temperature coefficient	±0.03%F.S/10℃	Sensitivity temperature coefficient	±0.03%F.S/10℃

Drawings of sartorius compression 10 ton 20 ton 30 ton load cell weighing

CHBU

Applications of sartorius compression 10 ton 20 ton 30 ton load cell weighing scale

Widely used in a variety of electronic scales, cement silo, powder mixer and industrial automation measurement and control system.
