Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency

    Buy cheap Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency from wholesalers

    Buy cheap Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency from wholesalers
    • Buy cheap Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency from wholesalers

    Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency

    Ask Lasest Price
    Brand Name : TOPLED
    Model Number : Outdoor P6
    Certification : CE ROSH FCC
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Square Meters/month
    Delivery Time : 5 Square meters /10 -15 working days
    • Product Details
    • Company Profile

    Full Color Outdoor Led Display Screen , P5 - P10 Led Display Panel Good Consistency


    High Brightness Big size outdoor & Indoor P5 / P6 / P8 / P10

    Outdoor advertising LED Display Screen


    Characteristic

    1. Bright color, high contrast, good consistency and high brightness to keep the high resolution of the video under the sunlight.

    2. Adopt CNC technology in high precision processing box body, the whole screen flatness<0.2mm. Using connection frame steel structure, installation and maintenance is very convenient.

    3. Red LEDs were powered by 3.2V, blue and green LEDs were powered by 3.8V, which make the screen work stable and prolong the life span.

    4. With PFC high-efficiency power supply, to ensure the screen can be powered sustainable.


    Application

    Outdoor far viewing distance (10m-80m) Led Display has the ability to play monitor videos and graphic information in real time. So it can be widely used in large area such as transportation, electricity, water conservancy, security, military conferences, city management, radio and television industries etc.


    Attention

    In order to offer you a suitable solution, Please state general info about your project.

    1. Pixel pitch or view distance you need.

    2. Dimension

    3. Location of installation. ( eg, on poles, on wall of building, etc)

    4. Purpose. ( what are you going to do with the LED Screen)


    Parameter


    P8

    Pixel pitch

    8mm

    Physical Density

    15,625mm

    LED Configuration

    1RGB

    LED type

    SMD3535

    Module Size

    320(mm)*160(mm)

    Module Resolution

    40(px)*20(px)

    Module Power Consumption

    25W

    Driving Method

    Constant Current IC

    Scan Method

    1/3

    Horizontal Viewing Angle

    140

    Vertical Viewing Angle

    140

    Brightness

    >=6500cd/sqm

    Grey Scale

    16bit

    Refresh Rate

    >=1920Hz

    Canbinet Resolution

    320(px)*360(px)

    Canbinet Max Consumption

    950

    Canbinet Average Power Consumption

    313.5

    Canbinet Size

    1024(mm)*1024(mm)

    Canbinet Weight

    8.1KG

    Canbinet Thickness

    85mm

    Canbinet Material

    Die-casting Aluminum

    Color

    >16.7

    Input Voltage

    AC110V~220V +/-10%

    Frame Frequency

    >=60

    Protection Level

    IP65

    Working Environment

    Indoor

    Working Temperature

    -40° -+65°

    Storage Humidity Range

    10%-90%

    Life Span

    100,000



    Why so many clients choose TOPLED?


    Our led display has applied many countries in the world. Many countries have our projects.


    TOPLED's led display unique advantage


    -------service


    >Our engineer will be on your service. We can give you technology support at any time.

    We will be tracking your orders, from the pre-sale to the after-sale and also serve you in this process.


    --------price


    Our price is based on the quantity, We have the basic price for one square meter. For each additional 5 square meter will have a discount when beyond 10 square meter. What is more, free power and fan will send to you. The cabinet will be free.


    --------Quality


    Quality is our reputation, we have eight steps for our quality inspection, From material to the finished goods. Quality is what we pursuit.


    Choose TOPLED, you choose the cost-effective , high quality and good service.
