    100m Soil Test Drilling Machine Geotechnical Drill Rig With Mud Pump

    Ask Lasest Price
    Brand Name : Shitan
    Model Number : XY-1
    Certification : ISO9001
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50 sets per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    100m Soil Test Drilling Machine Geotechnical Drill Rig With Mud Pump

    100m Soil Boring Geotechnical Drill Rig With Mud Pump For Soil Testing


    Product description


    Soil Boring Geotechnical Drill Rig for engineering constructions, shallow depth mineral exploration, small size pile hole, water well boring and blasting hole

    • Multiple revolving speed grades with large torque meets different project need.
    • 2 or 4 -wheels trailer, portable, easy to move by towing the trailer.
    • Rotary drilling and cable percussion drilling.
    • spindle can turn 360° range .

    The Drill Rig Information


    Drilling Depth:100m,70m,50m,30m
    The Hole Diameter75mm,91mm,110mm
    Kelly52*59*4200mm
    Drill Pipe Diameter42mm
    Drilling Angle90°-75°
    Rig Dimensions(Length*Width*Height)1960mm*850mm*1340mm
    Weight (excluding power)480kg
    Swivel Head
    Spindle speed(3-speed)142/285/570 r/min
    Spindle stroke450
    upward displacement speed
    of idling vertical spindle
    0.05m/s
    Downward displacement speed
    of idling vertical spindle
    0.067m/s
    Spindle pull-down max15KN
    Spindle lifting capacity max25KN
    Gyrator
    The Vertical Speed (fore steps)71,142,310,620 r/min
    The Vertical Stroke450mm
    The Maximum Speed Of Vertical Load0.05m/s
    The Vertical Load Down The Maximum Moving Speed0.067m/s
    Max Feeding Force15KN
    Max Lifting25KN
    The Vertical Maximum Moving Speed1.25 KN.M
    Hoist
    Max.lifting capacity(1-speed,single rope)10KN
    Cable volume (number) of hoisting drum27m
    Wire rope dia.9.3mm
    Mud Pump
    TypesHorizontal reciprocating single-acting piston pump
    Displacement max95 L/min
    Equipped with motor77 L/min
    Allowable working pressure max1. 2Mpa
    Continuous working pressure0.7Mpa
    Suction pipe dia32mm
    Discharge pipe dia25mm
    Product Features
    1. The oil pressure feeding mechanism can improve drilling efficiency and reduce the labor intensity.

    2. A ball mounted card blessing mechanism replaces the chuck which can carry out without stopping the lever, easy to operate, safe and reliable.

    3. Handle concentration, easy operation.

    4. It is compact.The drill, water pump and diesel engine are installed on the same base, which occupies a small area.

    5. It is light in weight, strong in decomposition and easy to remove .And it can be used in plains and mountains

    Main features:

    1.With the hydraulic feeding mechanism, improve the drilling efficiency, reducing the labor intensity of workers.
    2.The rig is equipped with a ball on a cassette holding mechanism and a six side rod, the rod can be replaced without shutdown, high work efficiency convenient operation, safe and reliable.
    3.Furnished with hole bottom pressure gauge pressure indicator, and easy to master the status inside the hole.
    4.The handle centered, convenient operation.
    5.The drilling machine has the advantages of compact structure, small volume, light weight, convenient move.
