075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve

    Buy cheap 075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve from wholesalers

    Buy cheap 075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve from wholesalers
    • Buy cheap 075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve from wholesalers
    • Buy cheap 075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve from wholesalers
    • Buy cheap 075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve from wholesalers

    075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve

    Ask Lasest Price
    Brand Name : AFK
    Model Number : 075D
    Supply Ability : 3000 Set/Sets per Week
    Price : Negotiable
    Certification : None
    • Product Details
    • Company Profile

    075D Automatic Irrigation Valve Medium Pressure , Drip Irrigation Flow Control Valve

    075D Automatic Irrigation Valve Medium Pressure Drip Irrigation Flow Control Valve

    Specification

    No.ITEMTECHNICAL PARAMETERS
    1Materialnylon plastic body, NBR seal
    2Fluidwater
    3Fluid temperature≤43°C
    4Environment temperature≤52°C
    5Service voltage6-20VDC(can order latching type coil), 24VAC, 24VDC, 110VAC, 220VAC
    6Pulse width20-500mSec (only for latching type)
    7Coil resistance6 Ω
    8Capacitance4700uF
    9Coil inductance12mH
    10ConnectionG(BSP) female thread is regular, special order for NPT(3/4" and 1")
    11Size

    075D: 3/4", 20mm (BSP or NPT female)

    100D:1", 25mm (BSP or NPT female )

    100P:1", 25mm (BSP female)

    150P:1-1/2"(1.5"), 40mm (BSP female)

    200P:2", 50mm (BSP female)

    300P:3", 80mm (BSP female, male, flange)

    400P:4", 100mm (BSP female, male, flange)

    12Working pressure

    3/4" and 1": 1-10bar

    1.5"and 2": 1-10.4bar

    3"and 4": 0.7-14bar

    13Flow rate

    3/4": 5 m³/h

    1": 9 m³/h

    1.5"-2": 0.45-34.05 m³/h

    3"-4": 1.1-70 m³/h

    14Operation modevalve element lock position,valve open, release position, valve close.

    Irrigation System


    Inquiry

    Hi, my dear friend, if any interests, please send me an inquiry with the following information included as many as possible. You also can contact me directly. Your enquiry will be answered within 24 hours.

    We will be very much appreciated if you can provide the parameters as below:

    1. size

    2. connection: G male thread, G female thread, NPT male thread, NPT female thread, flanged.

    3. voltage

    4. latching type coil required? 6-20vdc voltage range can be equiped with latching type coil.

    5. quantity
