Spoken Compression Load Cell Alloy Steel Material Long Working Life

Name: Spoken Compression Load Cell Alloy Steel Material Long Working Life
Brand: TOP SENSOR
Price: 1 USD

Ask Lasest Price
Brand Name :	TOP SENSOR
Model Number :	CL-06
Certification :	CE
Payment Terms :	T/T, Western Union
Supply Ability :	2000 pcs per month
Delivery Time :	20-25 days
Price :	Negotiable

Add to Cart

Product Details
Company Profile

Spoken Compression Load Cell Alloy Steel Material Long Working Life

Spoken Compression Load Cell Alloy Steel Material Long Working Life

Spoken Load Cells CL-06

Spoken Load Cell, 1-7.5t Model: CL-06 CAPACITY: 1-7.5t Features: Alloy steel material, High Precision, Oil-proof, Waterproof IP66 Spoke type, easy installation, suitable for electronic truck scales, Platform scales and other electronic weighing devices

Spoken Load Cell, 1-7.5t
Model: CL-06
Capacity: 1-7.5t

Features:
Alloy steel material, High Precision, Oil-proof, Waterproof IP66
Spoke type, easy installation, suitable for electronic truck scales,
Platform scales and other electronic weighing devices

Dimensions:(mm)

SPECIFICATION
Precision:		C2
Rated Output:		2.0 ±0.01
Creep(%F.S/30min):		±0.05
Zero balance(%F.S):		±1.0
Input resistance:		750±10
Output resistance:		700±5
Insulation resistance:		≥5000(100VDC)
Temp. effect on span(%F.S/10℃):		±0.02
Temp. effect on zero(%F.S/10℃):		±0.02
Use temp. range(℃):		-30～+55
Excitation voltage(V):		9～12(DC)
Safety overload (%F.S)		150%
Ultimate overload (%F.S)		200%
Defend grade		IP67
Cable Length:		3 meters -6 meters
Wire Connection Method
