2x50 Power Line Stringing Equipment Technical Parameters
| Item | Product model | SA-ZY-2×50 Hydraulic Tensioner |
| Performance parameters | Rated tension | 2×50 or 1×100kN |
| Maximum tension | 2×55 or 1×110kN |
| Rated stringing speed | 2.5km/h |
| Maximum stringing speed | 5km/h |
| Corresponding tension force | 2×25 / 1×50kN |
| Maximum reverse traction force | 2x45 /1x90 kN |
| Maximum sustained traction speed | 5km/h |
| Structural parameters | Stringing drum | Bottom diameter | 1300/1500mm |
| | Number of slots | 2x5 |
| Maximum applicable diameter of wire | 40mm |
| Dimensions | 4300×2200×2700mm |
| Weight | 5500kgs |
| Main configurations | Engine | CUMMINS |
| Electrical system | 24V |
| Hydraulic pump | REXROTH |
| Hydraulic motor | REXROTH |
| Reducer | REXROTH |
| Hydraulic instrument | WIKA |
2x50 Power Line Stringing Equipment Configuration
·2 hydraulic dynamometers
·Hydraulic oil cooling system
·2 digital meter counters
·2 digital speed meters
·Control instruments for hydraulic system and diesel engine
·Hydraulic front stabilizer ·Grounding connection point
·Hydraulic power pack to control up to 2 separated drum stands with
hydraulic motor
2x50 Power Line Stringing Equipment Hydraulic Transmission
·The machine can realize step less speed
·The machine is provided with tension presetting system
2x50 Power Line Stringing Equipment Additional Devices
·Lighting system for the trailer
·Air brake system for the trailer(extra charge)
·2 hydraulic conductor clamps for drum change operations (extra
charge)
·Digital speed and meter counter
