    Aluminum LED Light CNC Metal Spinning Lathe , Aluminium Spinning Machine 110 Mm

    Ask Lasest Price
    Brand Name : BAISHUN
    Model Number : BS-SP1000
    Certification : ISO9001:2008; CE.
    Price : negotiation
    Supply Ability : 600 sets/month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Aluminum LED Light CNC Metal Spinning Lathe , Aluminium Spinning Machine 110 Mm

    Aluminum LED Light Cnc Metal Spinning Lathe , Aluminium Spinning Machine 110 mm


    Features:

    Blank Diameter: 5-1400mm

    Spin Material Thickness:

    Aluminum: 0.3-2.0 mm

    Copper: 0.5-2.0mm

    Iron and steel: 0.5-1.5 mm

    Stainless steel: 0.5-0.6mm

    Spin materials: steel, alloy and copper etc.

    Easy to operate with advanced digital control.

    Improve the production efficiency, machining accuracy and save the cost of human resources.

    Application: light, automobile, military, mechanic and other industries.


    Product Description:


    CNC Spinning and Turning Machine
    Items

    Technical Parameters


    ModelBS-SP1000
    Amount of RollersSync 2+
    Max. Diameter of MaterialΦ1000 mm
    Max. Swing Over SlideΦ750 mm
    Max. Length of Work Piece700 mm
    Thickness of Work Piece

    0.5-6 mm ( Aluminum, Copper)

    0.5-4 mm (Carbon Steel)

    0.5-3 mm (Stainless Steel)

    X Travel510 mm
    Z Travel780 mm
    Pushing Force for X Axis50 kN
    Pushing Force for Z Axis50 kN
    Pushing Force of Tailstock100 kN
    Guide Rail TypeLinear Guide Rail
    Width of Bed850 mm
    Rapid Traverse X/Z8/12 m/min
    Servo Power X/Z25/30 N.m
    Pulse Equivalent X/Z0.001 mm
    Positioning Accuracy0.015 mm
    Repetitive Positioning Accuracy0.008 mm
    Spindle NoseC11
    Taper of Spindle Bore120(1:20)Metric
    Spindle BoreΦ110 mm
    Spindle Speed1500 rpm
    Taper of Tailstock QuillMT5
    Travel of Tailstock500 mm
    Travel of Tailstock Quill250 mm
    Diameter of Tailstock QuillΦ85 mm
    Amount of Tools / Shank Size4+4 mm²
    Spindle Motor Power21kw

    Machining Accuracy

    It 6
    Surface RoughnessRa 1.25
    Overall Dimensions3.6x2.5x2.5 m³
    Net Weight8500 kg


    Our Service:


    1. 24 Hours after sales service by E-mail or Phone.

    2. 100% response rate.

    3. Engineers available to service overseas.

    4. OEM service is available

    5. Warranty: 12 months, beyond the warranty period, all spare parts offered to you with factory price.
