    Ridge Cap Roll Forming Machine Color Steel Tile Roll Forming Machine PLC Control System

    Ask Lasest Price
    Brand Name : LBM
    Model Number : LBM-RCT-Model 05
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 25 Set per month
    Delivery Time : 25-30 working days
    • Product Details
    • Company Profile

    Ridge Cap Roll Forming Machine Color Steel Tile Roll Forming Machine PLC Control System

    Ridge Cap Roll Forming Machine Color Steel Tile Roll Forming Machine PLC Control System



    1. Description of Ridge Cap Roll Forming Machine

    There are different roof flashing roll forming machines based on different technical requirements on the final products, however, in the market people most of time use three kinds of roof ridge cap roll forming machines. Roof ridge caps with pressed STEPs, Roof ridge cap without steps, and V shaped roof flashing without STEPs. It has to be pointed out that a Roof ridge caps without STEPS sometimes can be used both as roof ridge caps and as roof valley flashings. In addition, there is a similar machine, Glazed Tile Roll Forming Machine.

    LBM factory is manufacturing high quality metal profiles roll forming machines. The roll forming machines mostly exported to Australia, India, Singapore, Iran, Croatia, South Africa, Saudi Arabia, Russia, Indonesia, Malaysia, Thailand, etc.


    2. Main Technical details of Ridge Cap Roll Forming Machine

    Suitable Raw Material
    MaterialGI and GL coils
    Thickness0.3~0.5mm
    Coil width333mm
    Yield Strength235Mpa
    Main Technical Parameters
    Quantity of forming rollers stations14
    Diameter of forming rollers shafts60mm
    Roll Forming Speed0~10/min
    Forming rollers materialNo.45 steel, with quenched treatment
    Cutter materialCR12 mould steel, with quenched treatment
    Controlling systemPLC and Converter
    Electric Power requirementMain motor power: 5.5kw
    Electric voltageAccording to customer’s requirement



    3. Main components of Radge Cap Roll Forming Machine

    Main Components
    Decoiler (manual and automatic for options)1 set
    Guiding device1 set
    Roll Forming system1 set
    PLC control box1 set
    Hydraulic unit1 set
    Runout tables2 sets






    4. Our Advantages:

    DesignGermany COPRA software design
    Engineer5 engineers with more than 20 years experience
    Technician30 professional technician
    Facility22 sets advanced CNC production lines on site
    TeamPassionate Team
    ServiceInstallation engineers can reach your factory within 6 days
    Warranty3 years maintenance and whole life technical support
    After service24 hours professional service team




    5. Contact Us

    Jiangsu LeBron Machinery Technology Co., Ltd.
    Factory address:
    No. 551, the Zhenze West Road, Huazhuang Street, Binhu Distrct, Wuxi City, Jiangsu Province, China
    Telephone: +86-510-8202 1910

    Company address:
    1604#, Yangming Sicence & Technology Industry Center, No.855 Nanhu Avenue,Wuxi city, Jiangsu, China
    Zip Code: 214000
    Telephone: +86-510-8388 8805
    Fax: +86-510-8262 0085

    Contact Person:
    Alfred (Manager)
    Cell/Whatsapp/Skype: +86-15821208506
    Email: alfred@lebron-machinery.com
    Website: www.lebron-machinery.com
