Digital RS485 Output, Remote Transmission Inclinometer Sensor
Features
☆Digital RS485 output, remote transmission
☆K-2QJJ200A whole temperature range compensation
☆Small size, light weight
Application
☆engineering machinery horizontal measurement
☆Laboratory instrument leveling
Specification
| Type | K-2QJJ200 | K-2QJJ200A | K-2QJJ200C |
| Electric character |
| Input voltage | 5±0.25VDC |
| Input current | ＜40mA |
| Output mode | RS485 | 1～4V |
| Baud Rate | 19200 bpsbps | |
| Data updating | 25 Hz | |
| The scale factor | | 3±0.2 V/g |
| Performance index |
| Range | ±75° | 20° |
| Nonlinear (%FS) | 0.3%FS | 0.1%FS |
| Resolution (°/s) | 0.05° | 0.01° |
| Bias | 0.1° | 2.5±0.1° |
| Bandwidth | 5Hz |
| Start-up time (ms) | ＜1s |
| Environmental characteristics |
| Compensated Temperatures | | -40℃～70℃ | |
| Temperature (°C) | -40℃~+70℃ |
| Storage Temperature | -40℃~+125℃ |
| Physical Characteristics |
| Weight (g) | 50g |
| Dimensions | 38×38×15.5mm |
Note: Range can choose ±20°,±40°,±60°,±75°
Dimension
