| Supply voltage | |
| Load voltage L+ | |
| 24 V |
| Yes |
| Input current | |
| from supply voltage L+, max. | 400 mA |
| from backplane bus 5 V DC, max. | 150 mA |
| Power loss | |
| Power loss, typ. | 9 W |
| Analog outputs | |
| Number of analog outputs | 8 |
| Voltage output, short-circuit protection | Yes |
| Voltage output, short-circuit current, max. | 30 mA |
| Current output, no-load voltage, max. | 19 V |
| Output ranges, voltage | |
| Yes |
| Yes |
| Yes |
| Output ranges, current | |
| Yes |
| Yes |
| Yes |
| Load impedance (in rated range of output) | |
| 1 kΩ |
| 1 µF |
| 500 Ω; 600 ohms if common-mode-voltage reduced to <1 V |
| Cable length | |
| 200 m |
| Analog value generation for the outputs | |
| Integration and conversion time/resolution per channel | |
| 13 bit |
| 420 µs; 420 µs in the ranges 1 to 5 V and 4 to 20 mA; 300 µs in all
ranges |
| Settling time | |
| 0.1 ms |
| 3.5 ms |
| 0.5 ms |
| Errors/accuracies | |
| Operational error limit in overall temperature range | |
| 0.5 %; ±10 V, 0 to 10 V, 1 to 5 V |
| 1 %; ±20 mA, 4 to 20 mV |
| Basic error limit (operational limit at 25 °C) | |
| 0.5 %; ±10 V, 0 to 10 V, 1 to 5 V |
| 0.5 %; ±20 mA, 0 to 20 mA |
| Potential separation | |
| Potential separation analog outputs | |
| Yes |
| Isolation | |
| Isolation tested with | 2 120 V DC between bus and L+/M; 2 120 V DC between bus and analog
section; 500 V DC between bus and local ground; 500 V DC between
analog section and L+/M; 2 120 V DC between analog section and
local ground; 2 120 V DC between L+/M and local ground |
| Dimensions | |
| Width | 25 mm |
| Height | 290 mm |
| Depth | 210 mm |
| Weights | |
| Weight, approx. | 650 g |
