TY1x7.5 Tension Stringing Equipment 7.5kN Tension Machine For
Overhead Stringing Hydraulic Meter German
TY1x7.5 Hydraulic Tensioner
Applied for tension stringing of the transmission line conductors
and ground cables, and ADSS, OPGW optical cables.
Characteristics
Bull-wheel diameter: 1100mm
Max conductor diameter: 24mm
Max Optical fiber cable diameter: 21mm
Groove width: 220mm
Groove number: 1
Total weight: 850kg
Overall dimension (length*width*height): 2300×1250x1620mm
| Model | TY1x7.5 |
| Max continuous pull | 7.5kN |
| Main motor | Ningbo, China |
| Hydraulic meter | German |
| Rated displacement | 243ml/r |
Performance
Max continuous pull: 7.5kN
Max speed: 40m/min
Main configuration
Main motor: Ningbo, China
Hydraulic meter: German
Motor
| Rated displacement: 243ml/r | Rated pressure: 25MPa |
Unit torque: 39.2N.m/MPa | Max Oil temperature: 60 degree |
| Oil: YA-N46 (0~40 degree); YC-N32 (-30~0 degree) | |
Hydraulic Transmission
Closed hydraulic circuit
Configuration
Hydraulic meter
Hydraulic control system
Hydraulic oil filter
Manual brake system
Mechanical front stabilizer
Grounding connection point
BOYU Brief
BOYU company was established in 1993, a high-tech enterprise in
China, and we are specializing in R & D, manufacturing and sales of
all kinds of transmission line stringing equipment and tools such
as hydraulic puller, tensioner, conductor pulleys, anti-twisting
galvanized steel rope as well as providing accessories and
technical service for customers. After years efforts, we has
developed as one of the largest stringing equipment and tools
manufacturer in China which supply more than 200 varieties kinds of
goods now.
Our annual output value reaches more than thirty million USD, we
provide more than 1000 sets of equipment for customers in the Power
System, our products are very popular in China, and our main
customers include STATE GRID, CHINA POWER, EETC etc. We also
develop business in the International market more than 10 years and
more than 50 countries, our main customer STATE GRID is No. 2 of
the 500 TOP Companies in the world.
We start the business with Philippines from 2014, we have customers
Meralco, Ferrowelds, MB Versoza, Hansei, Jay engineering, WYN
power, Multi Discovery, Sta. Clara etc.,
Asia: South korea, Philippines, Pakistan, India, Thailand,
Cambodia, Viet nam, Indonesia, Malaysia, Nepal, Sri Lanka, Turkey,
Jordan, Tajikistan, Saudi Arabia
America: Mexico, Bolivia, United state, Ecuador, Chile, Peru,
Brazil, Panama, Argentina, Honduras,
Europe: Poland, United Kingdom
Australia: Australia
Africa: Algeria, Egypt, Tanzania, Kenya, Ethiopia, Angola, Sudan
Branch:
1. Indonesia Jakarta office
2. India Delhi office
Operation and Maintenance training
We supply free operation and maintenance training in our factory,
and cover all cost of accommodation in China.
We supply 3~5days engineering support for operation & maintenance
training on your work site, but you have to pay for the cost of
accommodation, transportation and round trip ticket.
