    Heavy Duty Design Turret Head Milling Machine CNC Knee Mill 350KG Max Load

    Ask Lasest Price
    Brand Name : Taesin
    Model Number : TX-3SMC4
    Certification : ISO CE
    Price : Negotiable
    Payment Terms : TT LC
    Supply Ability : 10000 Set Per Year
    Delivery Time : 15 Days
    • Product Details
    • Company Profile

    Heavy Duty Design Turret Head Milling Machine CNC Knee Mill 350KG Max Load

    Heavy Duty Design Turret Head Milling Machine CNC Knee Mill 350KG Max Load


    Turret Milling Machinne with 350KG Max Load Core Components:

    • Heavy duty design with robust construction and Meehanite cast iron body

    • Strong Milling head from Taiwan

    • Auto Lubrication and Coolant Device

    • The working table and guide rail are heating treated and precision grinding.

    • Grinding on slideways of column

    • Table face hardened and ground

    • Hardened and ground spindle gear.

    • Dynamically Balanced Motor and Ground Pulleys.

    • Chrome-Plated and Bearing Supported Motor Shaft Provides An Extremely Smooth, Low Vibration Quiet Drive.

    • High Precision Spindles Use Class 7 Angular Contact Bearings.

    • The Dovetail and Square Slideways of The Table

    • The hard chrome quill is ground to mirror finish to ensure smooth movement.

    • Z Direct Drive Connection between the motor and spindle

    • XYZ Servo Motor

    • X Travel 980mm

    • Taiwai SYNTEC CNC System

    Turret Milling Machinne with 350KG Max Load Technical Data:



    Technical Data

    Model


    3SMC4

    Working Table Size (mm)

    1470*320

    X Axis Travel (mm)

    880

    Y Axis Travel (mm)

    380

    Z Axis Travel (mm)

    400

    Spindle Diameter (mm)

    85

    Spindle Travel (mm)

    100

    Spindle Speed RPM

    6000

    Spindle Taper

    R-8 (NT30)

    Spindle Horsepower

    3HP

    Spindle to Table Distance (mm)

    440

    Size (mm)

    2200*1650*2300

    Weight

    1480KG


    Technical Data

    Model

    MC43M3MB
    Working Table Size (mm)1270*2541270*2541370*280
    X Axis Travel (mm)680745860
    Y Axis Travel (mm)360400400
    Z Axis Travel (mm)400350350
    Quill Diameter (mm)858686
    Spindle Travel (mm)127127127
    Spindle Speed RPM80-544080-5400rpm80-5440
    Spindle TaperR-8 (NT30)R-8 (NT30)R-8 (NT30)
    Spindle Horsepower3HP3HP3HP
    Spindle to Table Distance (mm)440440440
    Size (mm)1800*1650*23001600*1700*22001600*1700*2200
    Weight KG138012001350
