Spindle Speed Taiwan CNC Milling Machine Max Load 150KG 10000 mm/min

Spindle Speed Taiwan CNC Milling Machine Max Load 150KG 10000 mm/min

Fixed Double Column Gantry CNC Milling Machine with high stability and precision; The working table moves along with the X axis, and the spindle travels with the Y Axis crossbeam and move vertically at the same time.

This Taiwan CNC Milling Machine has some functions: Once clamping, this CNC Milling Machine can do milling work in sequence; Rigid frame body, rectangular hardened rails can lead to high durability; Vertical axis structure can adjust milling quantity and height tolerance; Arc sliding table can slightly adjust the surface’s balance; Servo driven workpiece axis can rotate back and forth frequently and graduate precisely; Special pneumatic clamps can fix stably and precisely. This CNC Milling Machine can carry with truss or joint robot and automatic production line.

This CNC Milling Machine base, column, spindle box, table and other basic parts, all adopt high-intensity Lost Foam molding technology, the internal microstructure stability, to ensure that the basic pieces has high stability. Casting structure through the machine dynamics analysis and finite element analysis, geometric structure to make it more reasonable, and the appropriate combination of ribs to ensure the high stiffness of the basic parts. Wide machine bed base, full load support design, to ensure that the heavy load when processing capacity.

This CNC Milling Machine has wide base design with three sets of precision linear roller ways and 5 sliding block on X and Y axes, and two sets of precision linear roller ways and 6 sliding blocks on Z aixs. The machines are suitable for both rough and finish machining because of high rigidity, precision and stability. Ball screw's driving end equipped with 4 precision angular contact ball bearings and the other end with 3 ones, ball screw pre-extended.

TXC540 CNC Milling Machine Core Components:

TXC540 CNC Milling Machine Technical Data:

     Dongguan Taesin CNC Technology Co., Ltd specializes in the R&D, production and sales of CNC Machinery, including Vertical Machining Center, Horizontal Machining Center, Vertical Drilling&Tapping Machine, High-speed Engraving and Milling Machine, Double Column Machining Center.

     Taesin CNC Machines are designed and crafted into a master piece of art. Every single one of our machines is designed to have at least 20 year life span. The stability and duration after long-lasting work depend on Taixin’s focus on every technical detail, innovation and sustainable development. Taixin’s business philosophy--"Responsibility, Creativity, Honesty, Faith, Diligence, Fairness and Law" ensures the strict quality management and assurance.

     Taesin CNC Machines feature in high rigidity, enduring precision, efficiency And optimum stability. Taixin's wide range of CNC Machines allows us to cater to various demands of all industries such as locomotive, aerospace, 3C, medical, mold etc. Industry

      Customers are welcomed to come to our factory to find out what Taixin can do to meet your machining needs.
