X6520 Right Angle internal thread R1/8 Super-rapid fittings
Siphonate
| Materials | 1 = Body
2 = Seals
3 = Supporting ring
4 = Clamping gripper
5 = Locking bushing
6 = Release bushing | Stainless steel 316L
FKM Alimentary
Stainless steel 316L
Stainless steel 301
Stainless steel 316L
Stainless steel 316L |
| Threads | GAS conical ISO 7 (BSPT)
GAS cylindrical ISO 228 (BSP) |
| Pressure | max 18 bar (see tubing) |
| Tube to connect | PA 6-12, Rilsan PA11, Polyethylene,
PU, Polyester Hytrel |
| Diameters | 4 - 6 - 8 -10 - 12 mm |
| Fluid | compressed air and drinking water
(for other fluids, please contact our technicians) |
| Temperature | -15°C ÷ 150°C
NOTE: for a better use of the fitting we recommend
to check the tubing specifications. |
1.They are suitable for applications in the pneumatics
fluids,chemical, medical, food and packaging industries.
