    High Professional Vacuum Brazing Furnace 1350℃ Max Furnace Temperature

    Ask Lasest Price
    Brand Name : EasyFashion
    Certification : ISO9001:2008
    Price : To be discussed
    Payment Terms : T/T, Western Union
    Supply Ability : 2-10 sets per year
    Delivery Time : 180 working days
    • Product Details
    • Company Profile

    High Professional Vacuum Brazing Furnace 1350℃ Max Furnace Temperature


    Vacuum Brazing Furnace


    I. Overview

    Vacuum brazing furnace is principally adopted in Al brazing, Cu brazing and stainless-steel brazing of aerospace devices, vehicle components, electronic communicating devices, home appliances, heat exchanger and various heat radiators.


    II.Technical specifications

    Specification/ ModelEFZK-QH-50EFZK-QH-100EFZK-QH-200EFZK-QH-300EFZK-QH-400
    Rated loading capacity (kg)50100200300400
    Max. furnace temperature (°C)1350
    Temperature controlling precision (°C)≤±5
    Rated power(kW)5090120150180
    Rated supply voltage (V)380
    Rated heating voltage (V)Based on design. Furnace-front transformer is equipped.
    Ultimate vacuum degree (Pa)≤6.67 (empty furnace in cold status)
    Vacuum pressure rising rate (Pa/24h)≤50
    Gas cooling pressure (Mpa)≤0.1Mpa
    Working zone size (mm)300*300*400300*300*500450*400*670450*400*850600*600*1000
    Configuration of temperature controlling systemProgrammable regulator of Japan SHIMADEN
    Configuration of vacuum systemRotary vane pump+ Roots pump
    Note: The above is standard configuration which is adjustable based on customer requirements.

    III. Features

    1. Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure. Customers avail from various choices to fit their specific application needs.

    2. Heating chamber of this vacuum brazing furnace is fitted with temperature control deployed in several zones. Hence, outstanding heat uniformity is aggressively guaranteed.

    3. Well-conceived thermal insulation shield is available in this vacuum brazing furnace, whereby promoting heat efficiency.

    4. Vacuum system of this vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.
