    PET / PE / PVC Film Window Patching Machine With Bottom Friction Box Feeder

    Ask Lasest Price
    Brand Name : Allfine
    Model Number : 900TC
    Certification : CE;ISO;UL
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10sets/month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    PET / PE / PVC Film Window Patching Machine With Bottom Friction Box Feeder

    Full-automatic high speed PET/PE/OP/PVC film window patching machine for package paper box
    screen printing production line.pdf

    Main Datas
    ModelLC-900TC
    Max. Sheet Size900×500mm
    Min. Sheet Size150×100mm
    Max. Film Size450×280mm
    Min. Film Size20×20mm
    Film Thickness0.1~1.0mm
    Max. Working Speed500-2200pcs/h
    Cardboard120~700gsm
    Corrugated Board≤5mm
    Total Power11.3kw
    Weight2000kgs
    Dimension(LxWxH)7200×2360×1550mm

    1. Bottom friction box feeder ensures smooth and stable box feeding.
    2. Photo-electric tracing and central controlfor box feeding and correction before gluing.
    3. Air suction pass the cutted film preciously to the window area for gluing.
    4. Shaped film must be cutted well before appliaction on this machine, so it can do various shaped box.
    5. PLC, man-machine interface, central control are adopted to realize the automatic functions of box feeding, conveying, gluing, film patching and collecting before folding boxes.
    6. Screen printing glue applicater with even and solid glue application on the box.
    7. Button and touch screen setting for easy operation.

    HD video link about LC-900TC auto window patching machine
    https://youtu.be/v5FsIQShpms
    https://youtu.be/AsCKvwn-kow


    Configuration list
    NO.NAMEMODELSUMMADERREMARK
    1Electromotor3P 380V 2.2kw1HAIGUANG

    Main motor
    (with brake)
    1020 5.0KW

    2Electromotor3P 380V 0.37kw1HAIGUANG

    Squeegee
    (with brake)

    3Electromotor3P 380V 0.37kw1HAIGUANG

    Feeder table
    (with brake)

    4Vortical pump3P 380V 1.1kw1HENGLIDelivery table
    5Mulriple pump3P 380V 3.0kw1WeiteliCylinder
    6Mulriple pump3P 380V 3.0kw1WeiteliFeeder
    7Electromotor220V 0.09kw1T.W.T

    Delivery table
    1020 pneumatic

    8Electromotor220V 0.12kw1LINIXPaper advancing holder(optional)
    9InverterFR-E740-3.7K1MITSUBISHI

    JAPANESE
    1020 7.5K

    10PLC moduleCPM2AE-60CDR1OMRONJAPANESE



    For more information, please add my whatapp/viber/mobile/wechat/qq:+8615325773210



    1.Warranty Time:12 months/one year.

    2.Our aim:Customer is the God, if you not buy the first time,it will be your fault, if you buy but not buy second time, it will be our fault.
    A replacement can be made after the confirmation made by our related department when parts breakdown under the condition of right used within warranty period. The company develops file for every single machine that is made. Serial numbers are marked on each machine part and archived. It’s pretty convenient for our clients to change spare parts when necessary. The only thing you need to do is to provide us the serial numbers on the spare parts, which need to be replaced. Moreover, we provide one year warranty after sale. We offer free spare parts within the warranty time, except damages caused by human factors and irresistible external factors.

    3. If buyers damaged any parts of the machine without abiding by the using condition, using environment and usage that the instruction manual demanded within warranty time, we will only provide paid services under this situation.

    4. There will be an operation training for operator:
    (1) Training for right operation;
    (2) Training for common sense of daily maintenance;
    (3) Introducing after-sale services and training for solutions;
    (4) Introducing after-sale services and notify the contact way; Accessories supply guarantee: We supply free accessories within one year warranty period. We will charge you for accessories supply when the warranty is overdue;
