532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation

    Buy cheap 532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation from wholesalers

    Buy cheap 532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation from wholesalers
    • Buy cheap 532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation from wholesalers

    532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation

    Ask Lasest Price
    Brand Name : Xinland
    Model Number : XL-T532D5W
    Certification : CE
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000pcs per months
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation

    532nm 5000mw Digital TTL Modulation Green DPSS Laser Kit Module


    Specifications:


    ModelXL-T532D5W
    Wavelength532nm
    Operating modeCW
    Output power>5W
    Spatial modeNear TEM00
    Longitudinal modeMulti
    Spectral linewidth1.0nm
    PolarizationLinear vertical
    Polarization ratio>100:1
    Beam qualityM2<2
    Beam divergence full angle1.5 mrad
    Beam diameter at aperture3mm
    Beam pointing stability0.03mrad
    Power stability±5% over 8 hrs rms
    Optical axis height68.5mm
    Cooling modeTEC
    Operating votage90-260VAC
    Warm-up time10mintues
    Operating temperature10-35℃
    Storage temperature-20-60℃(<90% relative humidity, non-condensing)
    Expected life time10,000 hours
    Warranty time1 year

    Features:


    Green DPSS Laser, Scientific study laser , Output Power up to 5W,TEC cooling system Lightweight, compact design,Superior beam quality Low noise,Best reliability and lifetime
    Low cost and easy operating


    Application:


    It is wildly used in fields of Medical, laser demonstating,isotope separation,high density optical storage, Precision material processing,photoetching, spectrum analysis and so on.


    Payment Terms:

    Bank Wire Transfer, Money Gram, L/C, PayPal


    Quality 532nm 5000mw Green DPSS Laser Kit Module Digital TTL Modulation for sale
