Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic

    Buy cheap Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic from wholesalers

    Buy cheap Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic from wholesalers
    • Buy cheap Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic from wholesalers
    • Buy cheap Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic from wholesalers
    • Buy cheap Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic from wholesalers

    Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic

    Ask Lasest Price
    Brand Name : PERMIX
    Model Number : PMC100
    Certification : CE
    Supply Ability : 5-10 units per month
    Price : Negotiation
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Flexible Layout Planetary Cement Mixer PMC250 Cast Stone Materials Hydraulic

    Flexible Layout Planetary Cement Mixer Cast Stone Materials PMC250


    Maintaining Door


    The safety control device ensures that the mixer will not start during maintenance. Large size maintaining door for easy maintenance and cleaning.


    Hydraulic Unit


    The hydraulic discharging system is equipped with manual door opener, which can be opened manually in case of power failure.


    Discharging Door


    The limited switch installed, can be convenient to set the size of the door according to the need. At most three discharge doors can be opened.


    According to the material situation, different device can be selected to make the stirring speed faster, and the stirring is more uniform, without the phenomenon of stacking.


    Hydraulic System Maintenance Instruction


    1.Switch off the auto-control loop while using manual hydraulic system. Turn on manual stop valve and pull switching handle on the manual pump to the utmost. Then pull the handle to open the discharge door. Pull the handle in reverse to close the discharge door;

    2. Before starting the hydraulic system, ensure nobody inside the machine and all he manual valves have been switched off;

    3. The pressure of flood valve has been strictly adjusted to standard. Non-professional persons are forbidden to adjust the pressure;

    4. ISO-UNI HM46 hydraulic oil is recommended. Fill the oil to two thirds level of the indicator.


    Features of Planetary mixer


    Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. In addition to the equipment within the knife scraping wall around the cylinder axis rotation, will be stuck on the wall material scraping and then put them into mixing shear, that make no residual material in the mixer and mixing effect is more ideal. Cylinder with special seal structure and have the pressure or vacuum stirring. Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely.


    Technical Data
     PMC50

    PMC

    100

    PMC

    150

    PMC

    250

    PMC

    330

    PMC

    500

    PMC

    750

    PMC

    1000

    PMC

    1500

    PMC

    2000

    PMC

    2500

    PMC

    3000

    PMC

    4000

    PMC

    4500

    Output capacity(L)501001502503305007501000150020002500300040004500
    Input capacity(L)75 22537550075011251500225030003750450060006750
    Input capacity(kg)120 3606008001200180024003600480060007200960010800
    Diameter of Mixing Tank(mm)   130015401900219224962796310034003400
    Mixing Power kw37.5111518.5223037557590110160200
    Blade QTY1/21*21*21*21*21*21*32*22*23*23/63/93/93/9
    Side Scraper QTY11111111111111
    Bottom Scraper QTY11111111112222
    Weight(kg)700 1000120017002000350060007000850010500110001600018000
