P3 Indoor Fixed LED Screen with High Definition Fixed Quick Installation

P3 Indoor Full Color LED Display with High Definition Fixed Quick Installation

Specification:

1.LED Module
Dot Pitch(mm)		3mm			Size(W×H)		192*192mm
Pixel Point(Dot/ m2)		111111 dots/m2			Resolution(W×H)		64 * 64 dots
2.LED Lamp
3. Simply Cabinet or Wall Frame
Module sizes			192*192mm
Cabinet Size(W×H)			fixed installation : 960mm * 960mm (rental: 576*576mm)
Module Weight(g/pcs)			About 185g/pcs
4.Led Display Specification
ITME			SPECIFICATION
LED Display			Best View distance:3~15m
			Viewing angle-Horizontal :140 degree;
			Viewing angle-Vertical :120 degree
			Environment Temp: -40ºC ~ +85ºC
			Working Temp: -20ºC ~ +50ºC
			Operating Humidity Range:≤10~95%
Power Supply			Operating Voltage: 220V±5%
			Average Power: 200W/m2
			Max Power: 400W/m2
Control System			Control mode:asychronous/ synchronous control
Main Technical Parameter			Full white brightness:≥1000nits
			Driving IC:SMD2121 Led Driver
			Scan mode:1/32 scan
			Frame frequency:≥60 HZ/s
			Refresh rate:≥960 HZ/s
			Grey scale levels/Color processing:65536levels, Process 16.7M colors
			Brightness adjustment mode: 100 levels available
			MTBF:≥10,000 hours
			Life-span:100,000 hours
			Flatness:neighbor pixel≤0.5mm;module joint gap<1mm ;
			Uniformity:pixel light intensity, module brightness uniformity

Product Features:

1) High brightness(>1000cd/㎡ ), adjustable.

2) Clear vivid image quality.

3) Good Raw Materials: Naitonstar/Kinglight led chip, Chipone/MBI IC, G-energy/Chenglian/ Meanwel
Power Suppl.
4) Installation is simple by fast lock.

5) High stability and long span: Aging test at least 24 hours before shipment, 100, 000 hours life span.

6) Cabinet: Diecasting aluminum rental cabinets 576*576mm or standard iron waterproof 960*960 cabinets.

7) Package: Flight case, wooden box package & carton box and so on.

8) Guarantee:2 years.

Application:

Our full color LED display are widely used in commercial advertising, entertainment industry, financial industry, communications, power sector,
traffic, stadium, plaza, school, airport, bus station etc., for advertising and displaying messages.
