    Portable Earthing Devices Earth Clamp Meter Earth Insulation Tester

    ETCR2000 Series Earth Clamp Meter


    ETCR2000 series Earth Clamp Meter is widely used in the grounding resistance measurement of electric power, telecommunications, meteorology, oilfield, construction and the industrial and electrical equipment.

    The measurement does not require disconnecting the grounding wire, need no auxiliary electrode.


    It is safe, fast and simple in use. It equips long jaws or round jaws. Long jaw is particularly suitable for the occasion of grounding with the flat steel. It also be able to measure the leakage current and the neutral current in the grounding system.

    ModelJaws sizeResistance rangeCurrent rangeData uploadAlarmData save
    ETCR2000ALong type 65×32mm0.01Ω-200Ω××××
    ETCR20000.01Ω-1000Ω××××
    ETCR2000C0.01Ω-1000Ω0.00mA-20.0A×
    ETCR2000A+0.01Ω-200Ω××/√
    ETCR2000+0.01Ω-1200Ω××/√
    ETCR2000B+0.01Ω-1200Ω××/√
    ETCR2000C+0.01Ω-1200Ω0.00mA-20.0A×/√
    ETCR2000E+0.01Ω-1200Ω0.00mA-40.0A
    ETCR2100ARound type ∮32mm0.01Ω-200Ω××××
    ETCR21000.01Ω-1000Ω××××
    ETCR2100C0.01Ω-1000Ω0.00mA-20.0A×
    ETCR2100A+0.01Ω-200Ω××/√
    ETCR2100+0.01Ω-1200Ω××/√
    ETCR2100C+0.01Ω-1200Ω0.00mA-20.0A×/√
    ETCR2100E+0.01Ω-1200Ω0.00mA-40.0A
    FunctionGround resistance test, contact resistance test
    Resistance accuracy max±1%±0.01Ω
    Current accuracy max±2.5%±1mA
    Power Supply6VDC 4 PCS of AA Alkaline batteries
    *Alarm Threshold Setting Range*Resistance: 1-199Ω * C type only
    Alarm Sound and Light"Beep-beep-beep" alarm tone, Alarm Symbol Flashing, Press AL key to turn on, turn off Alarm or set Alarm Threshold.
    Interference Signal Recognition"Beep-beep-beep" tone, NOISE symbol blinking
    Working Temperature and Humidity-20°c-55°c; 20%RH-90%RH
    LCD Screen4 Digits LCD display, Screen L*W: 47mm*28.5mm
    Clamp Opening Extent32mm
    Tester Weight< 2KG
    Protection LevelDual Insulation
    Structural FeatureClamp CT
    range ShiftingAutomatic shifting
    External magnetic field<40A/m
    External electrical field<1V/m
    Single measurement time<1 second
    Resistance measurement frequency>1KHz
    Measured current frequency50/60Hz Automatic measurement
    Low Battery IndicationLow battery symbol displays when battery is lower then 5.3V
    Memory Full IndicationMEM symbol blinks when all 99 sets memory is full
    Over Range IndicationOut of range indication "OLΩ”, "L0.01" or "OL A"
    Auto Power-off5 minutes after Boot up
    Power ConsumptionMax 50mA either in booting up or normally working, Continuously working for 30 hours
    RS232 Interface (Optional)The data stored in the meter are uploaded to the computer through RS232 interface and data wire, Then generate report files
    AccessoriesMeter: 1 piece, Test ring: 1 Piece, Meter Suitcase: 1 Piece, Manual 1 Copy
