150KW Super Silent Diesel Generator Set with Deutz Engine , Canopy
Type
Detailed Product Description
| Commodity: | Canopy Type 150KW Silent Diesel Generator Set With Deutz Engine | Cummins Engine Model: | BF6M1013FCG2 |
| Stamford Alternator Model: | UCI274H | Control Panel: | Deep Sea 6020 / 7320 |
| Standby Power: | 206KVA / 165KW | Prime Power: | 188KVA / 150KW |
| Frequncy & Voltage: | 50HZ , 400V/230V | Engine Speed: | 1500 RPM |
| Type: | Silent Canopy Type | Cooling Method: | Water-cooling Type |
| Control Mode: | Manual & Auto Start | Total Lubricant Capacity: | 19 L |
| Circuit Breaker Type: | 3 Pole MCCB | Canopy Color: | White, Yellow, Blue, Red Etc. For Your Choose |
| Testing: | Debugging Before Shipment | | |
Engine Output Ratings:
Gensets Model | Prime | Standby |
| kW | kVA | kW | kVA |
| SP206DES | 150 | 188 | 165 | 206 |
| Voltage | 380V-415V | 220V-240V | 190V-208V |
| Amps | 261-285 | 451-492 | 520-570 |
Ratings and Performance Data of TP206DES:
| Engine Brand | Deutz |
| Engine Model | BF6M1013FCG2 |
| Alternator Brand | Stamford |
| Alternator Model | UCI274H |
| Control System | DSE6020 / DSE7320 |
| Standard Noise Level@7m | 72 db |
| Circuit Breaker Type | 3 Pole MCCB |
| Frequency & Phase | 50Hz & 3PH |
| Engine Speed: RPM | 1500 |
| Fuel Tank Capacity: L | Open | 385 |
| Soundproof |
| Fuel Consumption (l/hr) | 110% Load | / |
| 100% Load | 38.5 |
| 75% Load | / |
| 50% Load | / |
| Lubricant | 15W40-CF4 Upgrade |
| Total Lubricant Capacity (L) | 19 |
Standard Configuration of Silent Diesel Generator Set:
1) Cummins engine
2) Stamford alternator(Marathon, Mecc Alte, Chinese Wattek brand
for option)
3) Deepsea DSE6020 control panel (DSE 7320 Optional)
4) Chint circuit breaker
5) 8 Working Hours Base Fuel Tank (for the genset ≤ 650kVA prime,
only Base Frame for other models)
6) Anti-Vibration Mounted System
7) Battery, battery charger and battery isolator switch
8) Industrial silencer and flexible exhaust hose
9) Cummins tools
Features of DEUTZ Silent Diesel Generator Set:
1. International Warranty Service
2. Short delivery time, as we always have Cummins engine in stock
3. With ISO9001&CE certification
4. Spare parts are easy to get from worldwide market with much
cheaper price
5. Coupled with Stamford alternator, Marathon alternator or Chinese
Wattek alternator
6. Perfect after-service network
7. Both 50Hz and 60Hz
8. Rigorous test including 50% load,75% load,100% load and 110%
load
Stone Power,Located in Nanjing,China,which is the flourishing area of the
world manufacturing,one of the largest manufacturing bases of
diesel generater set in China,covering an area of 35,000㎡ and with
a 10,000㎡ assembly workshop. StonePower is specilized in designing
and manufacturing multi-cyclinder and multi-series industrial
diesel generator sets, water pump units and relevant equipments for
a variety of application ,such as telecommunication system, data
center, mining, electric power, harbor equipment , engineering
companies, financial systems, hotels, railways, airports,commercial
buildings, hospitals, factories and etc.
StonePower adopts internationally and domestically reputed high-uality
engines and alternators including Cummins,Perkins
Deutz,Mitsubishi,Lovol,YTO for our industrial diesel generator
sets, with power range from 20kW to 1500kW and various types of
design. With the compelling quality and service,StonePowerhas built
a good reputation with customers in the line of generator sets, our
products are exported to morethan 30 countries including Europe,
Americas ,Middle East, Africa, Asia and other regions.
We dedicate to make this work place safe and efficient. we are
proud of our management team and employees who have best quality
and deep experience in the industry. StonePower is dedicating to
establishing good relationship with customers through closed
cooperation and integrity. It has been constantly cooperating with
excellent international and domestic enterprises to utilize the
best resources to bring Stone Power to cultivate an international
brand.
