U Shape Electronic Lorry Weighbridge 80 Ton Capacity Sensor Load Cells

80 Ton U Shape Electronic Lorry Weighbridge Truck Scale Sensor Load Cells

Features of digital truck scales:

1. Numeral transformation technology and compensation
The Inner part of the weighing load cell contains module conversion device and CPU processing unit.
Auto-compensation with digital technology to the parameter of load cell such as non-linearity, temperature, etc.
Free of calibrating for the scale if the load cells are replaced.
2. With the calibrating and digital technology, bias-load (four corners) calibration of the truck scale can be completed only once.
3. Digital communications technology
The central line structure can be used by several weighing load-cells (up to 32) in the same system.
RS485 interface is used and long-distance signal transmission is possible, with the transmission distance not less than 1000m.
Output signal at 3~4V strengthens the capability of anti-interference and lightening protection of the system.
4. Intelligent technology
The parameter of the load cell can be changed according to the orders.
Different wave-filtering ways can be adopted according to different situations.
5. Module, standard and series scale body, multiunit assembly
6. Digital load cell of full-sealing column and laser-welded stainless steel, with accuracy of C3, strong water-proof and anti-corrosive function

1. Zemic load cell or Keli load cell; Optional
2. Waterproof junction boxes-1 set
3. Panasonic printer – 1piece
4. Main cable: 50m
5. 12mm thick steel surface avoid truck scale bending; 6mm thick strong U shaped structure
6. Design 6 pieces U beam design
7. U beam thickness design with 6mm
8. Pre camber machine to making platform have a high curves in Middle of platform
9. Auto welding machine to ensure welding is smooth and good strength
10. Shot blasting clean all dirty before painting

Pinglei is located in Shijiazhuang, Hebei Province, build in 2005. My factory is the largest weighbridge manufacture in North China. We have almost 100 employees in R&D, management, sales and production. We produce truck scales by our own design. Our annual sales reached 10 millions US dollars in 2008,and 80% of sales is from the oversea market.

Pinglei has got a certification of ISO 9001:2015.We concentrate all of our resources to provide the best prices to our customers with top-grade products. The design, manufacturing, inspection and test of our products meet customers demands and all related standards.

We have a strong R&D team who has rich experience in developing various scales, and constantly present new types of products according to the demands of oversea markets. We have various production and testing equipments which are necessary for producing products with high quality. Besides, we have many operators with rich experience, so each piece of our products could get the foreign customers hearty praise.

If you select Pinglei,it is just that you have chosen one advanced and reliable representative.

To choose Pinglei who is powerful and with abundant experience as your supplier, you will save more money and create more value.
