    PoE SMPS Flyback Transformer JA4456-DL_ For POE PD controller

    Ask Lasest Price
    Brand Name : Shareway
    Model Number : JA4456-DL_
    Certification : CE UL RoHS ISO9001:2008
    Price : Supportive
    Payment Terms : TT,Paypal
    Supply Ability : 3000K.PCS/Month
    Delivery Time : Stock or 3 weeks
    • Product Details
    • Company Profile

    PoE SMPS Flyback Transformer JA4456-DL_ For POE PD controller

    PoE SMPS Flyback Transformer JA4456-DL_ For POE PD controller


    Description:

    • Flyback Transformer For TI TPS23752 POE PD controller.

    • Developed for Texas Instruments green mode TPS23752 POE PD controller
    • 1500 Vrms, one minute isolation (hipot) primary and bias to secondary; 500 Vrms,

    one minute isolation primary to bias;750 Vrms all pins to the core.


    Core material Ferrite
    Terminations RoHS tin-silver over tin over nickel over phos bronze.
    Other terminations available at additional cost.
    Weight 11.7 g
    Ambient temperature –40°C to +125°C
    Storage temperature Component: –40°C to +125°C.
    Tape and reel packaging: –40°C to +80°C


    Part

    number

    Inductance

    at 0 Adc

    ±10% (μH)

    DCR max (Ohms)

    Leakage

    nductance

    max (μH)

    Capacitance

    max (pF)

    Turns ratio

    Ipk

    (A)

    Output
    prisecbiaspri : secpri : bias
    JA4456-DL_700.070.00430.3100.6151581 : 0.1821 : 0.4093.35 V, 5 A

    PoE SMPS Flyback Transformer JA4456-DL_ For POE PD controller


    Shape and Dimensions:


    Product picture:

    Quality PoE SMPS Flyback Transformer JA4456-DL_ For POE PD controller for sale
