    Single Screw PVC Profile Extrusion Line , SJ65 / 25 PVC Edge Banding Extrusion Line

    Ask Lasest Price
    Brand Name : YUREFON
    Model Number : Edge banding tape making machine
    Certification : CE SGS ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram,, Western Union
    Supply Ability : 200SETS/YEAR
    Delivery Time : 40 DAYS
    • Product Details
    • Company Profile

    Single Screw PVC Profile Extrusion Line , SJ65 / 25 PVC Edge Banding Extrusion Line

    PVC Edge Banding Tape Extrusion Line, PVC edge banding tape making machine


    Product Description

    PVC Edge Banding Tape Extrusion Line, PVC edge banding tape making machine

    1. Our company is cooperating with many universities to develop the urgently needed plastic machine. It also absorbs advanced technology from abroad to achieve the purpose of supplying complete machine and technology.


    2. PVC edge band making machine


    3. The PVC edge band Extrusion Line is used for extruding PVC edgeband. The edgeband in the form of roll has its thickness of 0.5-4.0 mm and width of 5-300mm depending on the requirments. Its length is not limited. This product is featured by its good banding effect, easy operation and high utilization rate, therefore it is applicable to mechanical banding of solid furniture, composite doors and WPC doors.


    Parameters of PVC Edge Banding Tape Extrusion Line, PVC edge banding tape making machine

    Item

    Technical parameter

    I. SJ65/25 Single Screw Extruder

    Supplier of electric control cabinet

    Main transducer and feeder's transducer: Hitachi transducer; Air switch:

    Output capacity

    80kg/h(approximate)

    Inlet wire terminal of power source

    3-phase, 4-wire system

    Motor power

    Main motor:AC30kw

    Temperature control curve type

    Temperature fluctuating self-adjustment(PID type)

    Temperature control meters, manometers and speedometers

    RKC(Japan) temperature control system, Xiaogan Wuyue(China) sensor and high quality speedometers respectively.

    Pressure display

    With melt pressure display

    Feeder type

    Vacuum feeder(with drier), with enganced screw feeder

    Connection of die head with flange

    By bolts

    The advantages over other companies in this field

    Good shearing, high output, reasonable design, high accuracy and easy control, high-grade materials and parts with steadfast performance.



    1. Screw


    Diameter

    65mm

    LD

    25:1

    Quantity

    1pcs

    With gas vent or not

    With



    2. Barrel


    Barrel type

    Integer

    Heating method

    Air cooling unit. Special stainless cover and red copper electricity heater are used on the barrel

    Heating zones

    7-zone

    Total heating power

    60kw(approximate)

    Temperature range

    50~300

    Cooling zones

    7-zone

    Cooling system

    7X0.55kw

    Cooling medium

    Air cooling

    Screw and barrel manufacturer

    Zhejiang Machinery Co., Ltd

    Quality guarantee

    Testing block and tested report are available. Guaranteed period is more than 10,000 working hours

    Nitrid depth

    0.6~0.7mm

    3. Driving system and speed reducing system

    Main driving motor power

    18.5kw

    Main motor working method

    3-phase asynchronous motor, connected to the gearbox by couple

    Main motor rotating speed


    Gearbox type

    Helical gear, hardened

    Gears

    Carburized and ground; The material is 20CrMoTi

    Main motor speed-adjusting method

    AC transducer



    II.Haul-off unit

    Haul-off speed

    20-30m/min(adjustable)

    Speed control method

    Inverter

    Motor power

    0.75kwX2



    III. Single disc winder

    Winding range

    15-25mm



    IV. Mould

    1 set
