Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height

Name: Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height
Brand: HYCM
Price: 1 USD

Ask Lasest Price
Brand Name :	HYCM
Model Number :	Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height
Certification :	CE, ISO
Price :	negotiation
Supply Ability :	40 sets per month
Delivery Time :	8-15 days after receiving the deposit or origin LC

Add to Cart

Product Details
Company Profile

Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height

Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height

Specification for Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height

Type		ZLP800 Suspended Platform
Rated load(kg)		800
Lifting speed(m/min)		8.2
Motor power(kw)		2×1.8 50HZ
Brake torque(Km)		15.2
Steel rope angle adjusting range(°)		3°- 8°
Distance between two steel rope(mm)		≤100
Rated stretch of front beam(mm)		1100-1700
Suspending Platform	Locking	Aluminum alloy
	Nr. of platform rack	Single rack
	Nr. of platform	3
	L×W×H(mm)	(2500×3)×690×1180
	Weight(kg)	217
Suspending mechanism(kg)		2×175 Kg
Counterweight(kg) optional		25×40pcs
Diameter of steel rope(mm)		8.6
Voltage(v) 3PHASES		380V or as per your inquiry

Features of Hot Sale 6m Length Platform ZLP800 Type Air Construction Swing Stage Lifter with 100m Height

1.Our suspended working platform can be widely used parapet and complicated building in different height. And we can also supply customized platform to meet different requirements from customers.

2. Besides, Suspension Working Platform can be used to lift specific weight.

3.Suspension power Working Platform is a temporary, flexible high access equipment for maintenance and construction work. distinguished from permanent access equipment. It can be disassembled conveniently.

4. ZLP800 suspended platform uses LTD80 hoisting motor. It has electromagnetic brake motor, centrifugal speed limiting device, two steep speed reducer and “a” type rope winding system.

5. Suspension Working Platform is a good helper for construciton and decoration of high buildings.

6. It compared with traditional scaffolding, can save labours and time to maintain the high buildings, such as industry workshop, water tower, bridge, TV tower, big chimney, cenotaph, dam,etc.

7. Hoisting motor can wind rope automatically. Operator only need to insert rope into the motor.

Other HYCM brand products are recommended for you

SC200/200,SC100/100 Construction Hoist;

PT7532,PT7427, PT6518,PT6016,PT5515,PT5620,PT5210,PT5010 Topless Tower Crane;

TC7550,TC7050,TC7040,TC7030,TC6024,TC6018,TC6012,TC6010,TC5612,TC5610,TC5011,TC5010,TC4810 Topkit Tower Crane etc;

QTD5078,QTD6037,QTD6029,QTD5520,QTD5030,QTD5020,QTD4522,QTD2520 Luffing Tower Crane.

Why choose us

1. A professional tower crane supplier in China with 15 years experience

2. Exported to more than 20 countries with ISO9001 Certifications

3. Varialbe-speed frequency PLC control System

4. Operation data display screen and Safety monitoring system (Black Box)

5. Various safety devices
