Single Disc 250mm Automatic Grinding and Polishing Machine With Center Loading Polishing Head

Center Loading LCD Display Automatic Grinding And Polishing Machine With Polishing Head

Brief Introduction:

iGrind-817 has the features of stable and reliable performance, easy operation, wide application range and working process of the automation etc.

Technical Specifications:

Surface layers damaged by cutting must be removed by grinding. Mounted specimens are ground with rotating discs of abrasive paper, for example wet silicon carbide paper. The coarseness of the paper is indicated by a number: the number of grains of silicon carbide per square inch. So, for example, 180 grit paper is coarser than 1200 grit.

The grinding procedure involves several stages, using a finer paper (higher number) each time. Each grinding stage removes the scratches from the previous coarser paper.

This can be easily achieved by orienting the specimen perpendicular to the previous scratches. Between each grade the specimen is washed thoroughly with soapy water to prevent contamination from coarser grit present on the specimen surface. Typically, the finest grade of paper used is the 1200, and once the only scratches left on the specimen are from this grade.

The series of photos below shows the progression of the specimen when ground with progressively finer paper.

Polishing discs are covered with soft cloth impregnated with abrasive diamond particles and an oily lubricant or water lubricant.

Particles of two different grades are used: a coarser polish - typically with diamond particles 6 microns in diameter which should remove the scratches produced from the finest grinding stage,

and a finer polish – typically with diamond particles 1 micron in diameter, to produce a smooth surface.

Before using a finer polishing wheel the specimen should be washed thoroughly with warm soapy water followed by alcohol to prevent contamination of the disc. The drying can be made quicker using a hot air drier.

Mechanical polishing will always leave a layer of disturbed material on the surface of the specimen. Electropolishing or chemical polishing can be used to remove this, leaving an undisturbed surface.

DongGuan Q1-Test Equipment Co., Ltd. was founded in year 2000, located in DongGuan, a famous industrial city.


Mainly specialized in manufacturing, developing and marketing various environmental testing equipment like programmable temperature and humidity test chamber QTH series, walk-in temperature and humidity test chamber, thermal shock test chamber QT3 series, industrial drying oven, burn-in chamber, salt spray/corrosion test chamber QCC series.


All the Q1-Test products conform the standards of GB, BS, IEC, CNS, ASTM, ISO, JIS, DIN and other relevant international testing standards.


Q1-Test product is widely used in the field of aerospace, military, automotive components, optoelectronic, electronic parts, communication, furniture, building materials, chemicals, paint, inspection laboratory, research institutes and other high-tech industries.


We have powerful ability to design, develop and manufacture custom made products according to customer’s special applications, and will go on enlarge our products line, provide professional solutions, timely services and qualified products to feedback customers’ kind support and trust.


We are also looking forward extensively and deeply work with customers to create brilliant future together.
