2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide

    Buy cheap 2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide from wholesalers

    Buy cheap 2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide from wholesalers
    • Buy cheap 2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide from wholesalers

    2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide

    Ask Lasest Price
    Brand Name : HCB
    Model Number : CR123ASC/CR17335SC
    Certification : UL/RoHS/UN/CE
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : Two million units per month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    2100mAh CR123ASC Cylindrical Li-MnO2 Battery CR17335SC Primary Lithium Manganese Dioxide

    2100mAh CR123ASC Li-MnO2 Cylindrical Batteries CR17335SC Primary Lithium Manganese Dioxide


    Highest capacity CR123A currently known in the world

    CR17335SC Characteristics (23±2oC, in 1 year)
    • Open Circuit Voltage ≥3.1V
    • Nominal Capacity 2100mAh
    • Maximum Continuous Current 25mA
    • Battery discharged for minimum 50% of rated capacity
    • Maximum Pulse Discharge Current 100mA
    • Battery discharged for minimum 50% of rated capacity
    • with max pulse for 3 seconds after 27 seconds break
    • Storage Condition Temperature ≤ 30℃
    • Humidity ≤ 75%RH
    • Operating Temperature - 40~+85℃
    • Self-discharge Rate ≤2%

    1.Features
    High Voltage
    • Nominal voltage up to 3.0 V
    High Energy Density
    • Specific energy density up to 260 Wh/kg
    Wide Operating Temperature Range
    • -40°C to +85°C
    Long Shelf Life
    • Self discharge rate is less than 2% per year at room temperature
    • High capacity, stable performance, no passivation effect
    • Glass-to-metal seal
    • Bobbin and spiral structure is available for different applications


    2.Characteristics
    Lithium is the lightest of metals and it floats on water. It also has the greatest electrochemical

    potential which makes it one of the most reactive of metals. These properties give Lithium the

    potential to achieve very high energy and power densities permitting batteries with very long useful

    life and small cell packages.

    3.Because Lithium reacts violently with water, as well as nitrogen in air, this requires sealed cells.

    High-rate Llithium cells build up temperature and pressure if they are short circuited or abused. Thus,

    the cell design needs to include safety vents, which release the pressure or rupture to prevent

    uncontrolled explosion.

    4.Typical chemistries are Lithium Manganese dioxide, Llithium Sulphur dioxide, Lithium Thionyl Chloride

    (see below) and Lithium Oxygen (see below) but other variants are available.

    5.Advantages

    • High energy density, double that of premium alkaline batteries
    • Low weight
    • High cell voltage
    • Flat discharge characteristic
    • Low self discharge
    • Very long shelf life
    • Very long operating life (15 to 20 years for lithium thionyl chloride)
    • Wide operating temperature range ( -60 ° C to +85 ° C for lithium sulfur dioxide)
    • Excellent durability
    • Small cell size
