    Output PF0.9 Uninterruptible Power Supply 10 - 30kVA Emergency Power Off Function

    Ask Lasest Price
    Brand Name : HRD/OEM
    Model Number : PW plus 3/3-10K, 3/3-15K ,3/3-20K,3/3-30K
    Certification : ISO9001-2000,ISO9901-14001
    Price : usd 1000-3000/pcs
    Supply Ability : 200 units/ week
    • Product Details
    • Company Profile

    Output PF0.9 Uninterruptible Power Supply 10 - 30kVA Emergency Power Off Function

    Powerwell Plus series Online HF UPS 10-30kVA 3:3PHASE

    Main Features

    o True double-conversion

    o DSP technology guarantees high performance

    o Output power factor 0.9

    o Active power factor correction in all phases

    o 50Hz/60Hz frequency converter mode

    o ECO mode operation for energy saving (ECO)

    o Accepts dual-mains inputs (Only for 10K/15K/20K models)

    o Emergency power off function (EPO)

    o Generator compatible

    o SNMP+USB+RS-232 multiple communications

    o 3-stage extendable charging design for optimized battery performance

    o Adjustable battery numbers

    o Maintenance bypass available

    o Optional N+X parallel redundancy

    ModelPW plus 3/3-10K (L)PW plus 3/3-15K (L)PW plus 3/3-20K (L)PW plus 3/3-30K (L)
    PHASE3-phase in / 3-phase out
    CAPACITY10000 VA / 9000 W15000 VA / 13500 W20000 VA / 18000 W30000 VA / 27000 W
    INPUT
    Nominal Voltage3 x 400 VAC (3Ph+N)
    Input Voltage Range190-520 VAC (3-phase) at 50% load ; 305-478 VAC (3-phase) at 100% load
    Frequency Range46~54 Hz or 56~64Hz
    Power Factor≧ 0.99 @ 100% Load
    OUTPUT
    Output Voltage3 x 400 VAC (3Ph+N)
    AC Voltage Regulation (Batt. Mode)± 1%
    Frequency Range (Synchronized Range)46~54Hz or 56~64Hz
    Frequency Range (Batt. Mode)50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
    Current Crest Ratio3:1 (max.)
    Harmonic Distortion≦ 2 % THD (Linear Load) ; ≦ 5 % THD (Non-linear Load)
    Transfer TimeAC Mode to Batt. ModeZero
    Inverter to BypassZero
    Waveform (Batt. Mode)Pure Sinewave
    EFFICIENCY
    AC Mode90.5%91.5%91.5%92.1%
    ECO Mode96%
    Battery Mode87%88%88%89%
    BATTERY
    Standard ModelBattery Type12 V / 9 Ah
    Numbers20 pcs (18 - 20 adjustable)*20 pcs x 2 strings (18 - 20 adjustable)*20pcs x 3 strings(18-20 adjustable)*
    Typical Recharge Time9 hours recover to 90% capacity
    Charging Current (Max.)1A2A2A4A
    Charging Voltage273 VDC ± 1%
    Long-run ModelBattery TypeDepending on the capacity of external batteries
    Numbers
    Charging Current (Max.)4A4A4A12A
    Charging Voltage273 VDC ± 1%
    INDICATORS
    LCD DisplayUPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault
    ALARM
    Battery ModeSounding every 4 seconds
    Low BatterySounding every second
    OverloadSounding twice every second
    FaultContinously sounding
    PHYSICAL
    Standard ModelDimension, DxWxH (mm)815 x 250 x 826815 x 250 x 826815 x 250 x 826815 x 300 x 1000
    Net Weight (kgs)109164164233.5
    Long-run ModelDimension, D xWxH (mm)592 x 250 x 826592 x 250 x 826592 x 250 x 826815 x 250 x 826
    Net Weight (kgs)38404064
    ENVIRONMENT
    Humidity0-95 % RH @ 0- 40°C (Non-condensing)
    Noise LevelLess than 60dB @ 1 MeterLess than 65dB @ 1 Meter
    MANAGEMENT
    Smart RS-232/USBSupports Windows 2000/2003/XP/Vista/2008, Windows 7/8, Linux, Unix, and MAC
    Optional SNMPPower management from SNMP manager and web browser

    *When using internal batteries from 18-19, the unit will de-rate according to the below formula: P = PRating x N/20.


    Product specifications are subject to change without further notice
