    Servo Automatic Adjustment Pipe Making Machine Square Tube Mill

    Ask Lasest Price
    Brand Name : Tengtian
    Model Number : LW200
    Certification : CE ISO
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 50set per year
    Delivery Time : three month
    • Product Details
    • Company Profile

    Servo Automatic Adjustment Pipe Making Machine Square Tube Mill

    Servo Automatic Adjustment Pipe Making Machine Square Tube Mill

    welded pipe making machine consists of the following parts:
    1.Forming parts: Consist of seven frame of horizontal roll rack, four frame of empty curving rack, four frame of vertical roll rack and one frame of feeding rack
    2.Welding parts: consists of welding five roller of extruding roll, two frame of scraping scar rack and one frame of polish rack
    3.Sharping parts: consists of four frame of four roller rack
    4.Electric control part: controlled by multipoint PLC control

    Product Process:

    material(steel coil)→uncoiler→shear and welder→horizontal(or cage) accumulator→forming mill→
    HF soild welder→sizing mill→rounghly straightening(turkey head)→cut off machine→run out table


    The Basic Parameters:

    stands of forming mill7
    stands of sizing mill5
    square pipe size30×30-50×50mm
    square pipe thickness1.0-3.0mm



    ERW Tube Mill Other Model

    ModelDiameter RangePipe ThicknessLine Speed(m/min)
    LW20030*30-50*50MM1-3MM20-80
    LW60060*60-150*150MM2-7MM20-60
    LW80080*80-200*200MM1-3MM(or 4-13)20-40
    LW1000100*100-250*250MM3-12.7MM(or4-14)15-30
    LW1200120*120-300*300MM3-14MM10-25
    LW1400150*150-350*350MM4-14MM8-20
    LW1600200*200-400*400MM4-16MM8-20


    This model just for you reference,the product range and thickness is adjustable,we have ourselves engineer team,can design the machine according to the customer special require.

    Our Services
    1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
    2.) Warranty Team
    One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
    3.) We supply the pre-sell and after-sell service.
    pre-sell service: workshop design, and production output design
    after-sell service: installation and training, and the skilled engineer for working.
    4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
    5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.
    6.) We will be responsible for the loading and shipping
