Synchronous Controlled Indoor P 6.25 500 * 500 mm Rental LED
Display
Product features:
1. Lightweight
The aluminum die-casting technology makes the single cabinet as
light as 7.5kgs only, which is convenient for assembly and
transportation.
2. High refresh rate
The driving is using the new Taiwan technology for high
performance. The chips can generate a speed of > 3840Hz refresh
rate to ensure the picture wrinkle-less, line-less and stable.
3. No ghost effect
It is because we use the highest technology of driving chips that
also will improve the ghost effect. Ghost effect gives a bad
results on led display screens and now be eliminated.
4. Modular and easy to maintain
There is almost no more ribbon cables for the cabinet and module.
Everything connected straight on the PCB hub. Less cables means
less possible problems. And no need to disassemble the whole screen
for maintenance. Each component can be detached individually for
that purpose.
5. Seamless connection
The precision reach ±0.05m so as to achieve seamless assembly.
Stronger and better looking compared to normal cabinets.
Specification:
| Module Parameters | Pixel pitch | 6.25 |
| Pixel Density | 25600 pixels/m2 |
| LED Shape | SMD 3in1 |
| LED Configuration | 1R1G1B |
| Module Resolution | 40*40 pixel |
| Module Size | 250*250 mm |
| Drive Method | 1/10 |
| Cabinet Parameters | Cabinet Resoltuion | 80 *80 |
| Cabinet Size | 500*500 mm |
| Cabinet Weight | 7.5kg/cabinet |
| Display Parameters | Optical | Brightness | ≥1800 cd/m2 |
| Viewing angle | H/V 160/160 |
| Best Viewing Distance | 6-25 m |
| Display Color | 16.7 million |
| Grey Scale | 16bits |
| Power | Max power consumption | 800 W/m2 |
| Ave power consumption | 380 W/m2 |
| Working Voltage | 220V / 110V |
| Control system | Frame Frequency | 60--85 HZ |
| Refresh Rate | 4000 HZ |
| Data Transmission | CAT 5/ Optic Fiber |
| Image Source | S-Video, PAL/ NTSC |
| Controlling system | linsn, Nova, Colorlight |
| Format | Video Compatibility DVI, VGA, composite |
| Reliability | Working Temperature | -20~65 ℃ |
| Working Humidity | 10-95% RH |
| Life Span | 100,000 Hours |
| MTBF (Ave No Faliure Time) | 5000 Hours |
| Pixel failing Rate | 0.01% |
| IP Rate | IP 34 |
Aging Testing:
1. The test content: black and white, red, green, blue monochrome,
grayscale gradient,video effects,
text effects
2. White screen test playing time is not less than 24 hours
3. Monochrome and grayscale gradient test not less than 24 hours
4. Video and text effects test not less than 24 hours
Packing :
Pack with flight case or wooden case as required or based on order
Payment terms:
1. for small amount :100 prepaid before production
2. for up 5000 dollars: 30% deposit,balance before shipment
3. paid by T/T,Western union, Paypal as discussed
