    ISTA Standard Vibration Shaker Table For Precision Instrument Vibration Testing

    Ask Lasest Price
    Brand Name : LABTONE
    Model Number : EV320
    Certification : CE / ISO
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 15 Sets / Month
    Delivery Time : 45 Working Days
    • Product Details
    • Company Profile

    ISTA Standard Vibration Shaker Table For Precision Instrument Vibration Testing

    ISTA Standard Vibration Shaker Table For Precision Instrument Vibration Testing


    Feature


    • Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability;
    • Load center airbag has high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation;
    • High efficiency D class power switching, 3-sigma peak current, provide finest power consumption and minimize harmonic distortion;
    • Quick self-diagnosis with safety interlock, high safety reliability;
    • Airbag shock isolation device for vibration platform without the need of additional foundation, perfect reproduction of vibrational wave and reduce vibration transmittance;
    • Provide horizontal and vertical expansion platform for different application;
    • Simple controller operation

    Specifications


    system modelEV320
    frequency range (Hz)2-3000
    max sine force (Kg/KN)2000/20
    max displacement(mmp-p)76
    max acceleration(g)80
    max velocity(m/s)2.0
    max load(kg)1000
    shaker modelVG2000/76
    armature weight(kg)25
    armature diameter(mm)¢320
    cooling methodforced cooling
    shaker weight(kg)2000
    shaker dimensions(L*W*H)850*1000*1100mm
    power amplifier modelApm30k
    power amplifier weight(kg)550
    AMP.dimensions(L*W*H)800*550*1920mm
    power supply3PH AC380v±10% 50Hz
    aggregate capacity power40KW


    Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.

    Applicable Industries: Automotive, Electronics, Aviation, Vessel, Telecommunication, Military Industry, Measuring Instrument etc.


    FAQ:

    How do you attach the hardware you’re testing to your shaker?
    By means of a fixture, usually aluminum or magnesium for lightness coupled with rigidity. They can be cast, or smaller fixtures machined from solid stock. Most fixtures are welded.

    How do you control shakers?
    If we’re looking for resonances in the product we’re testing, we command the shaker to shake the product at one frequency at a time but to vary that test frequency, to sweep it over a range of frequencies.But more realistically, we command the shaker to vibrate randomly and to excite all the resonances simultaneously.Control commands go into the keyboard of a specially-programmed computer.

    What are those resonances?Are they bad?
    Have you ever noticed the steering wheel moving with rather large displacement amplitude, larger than the input to the column? That magnification is called resonance. Possibly it annoys you. There’s a slight chance that in a few years that whipping of the steering column might cause bending fatigue failure.When we shake an automotive or ship or land vehicle instrument, we're looking for, for example, portions of printed wiring boards (PWBs) responding with greater motion than we're inputting. That flexing may damage PWB wiring, it may damage the attached components, and it will damage the soldered connections between components and the PWB.
