Brand Name : | YUYANG |
Model Number : | YY1505 |
Certification : | GB/T3903.2 |
Price : | $500.00 |
Payment Terms : | Western Union, T/T, L/C,Paypal |
Supply Ability : | 4pcs /week |
Delivery Time : | 8-10days |
125~150cpm Outsole Flexing Tester Large Bottom Bending Footwear Testing Equipment
Description:
This machine is designed Tor flexing soles repeatedly. The specimen is mounted between two clamps and let the flexing axle pass through the cut on the specimen. When testing, the specimen is flexed at a specified angle for a given number, and then the length of cut growth is measured. This machine has the returning function, so it is convenient and time saving.
Parameters:
Displacement of moveable clamp | 41.5±0.5mm |
Diameter of moveable flexing axle | 30 ± 1mm |
Speed | 125~150cpm |
Flexing Angle | 90° |
Sampling | 3 pcs |
Counter | LCD,0~99,999,999 |
Dimension(W×D×H) | 100×53×30 cm |
Weight | 98kg |
Power | 1∮﹐AC 220V, 3A (Specified by user) |
